V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230336
SandenVendo America, Inc. HARNESS QUICK REFERENCE GUIDE
V21 VENDORS
DESCRIPTION PURPOSE 521 621 721 821
1122905 Door Harness
Connects motors, temp. sensors,
transformer, drop sensors, and relays to
X X X X
1111287
Selection Harness –
10 Selections
Connects the selection buttons to the
control board
N/A N/A X X
1117872
Selection Harness – 8
Selections
Connects the selection buttons to the
control board
N/A X N/A N/A
1188676
Selections
Connects the selection buttons to the
control board
X N/A N/A N/A
1204221
Selection Harness –
10 Select HV3
Connects the selection buttons to the
control board
N/A N/A X X
1126164 Display Harness
Connects the display to the control
board
X X X X
1122918
Motor Harness – 10
Select
Connects the vend motors to the door
harness
N/A N/A X X
1123050
Motor Harness – 8
Connects the vend motors to the door
X X N/A N/A
1121067
Select, Right
Connects the selection buttons to the
control board
N/A N/A X X
1121085
Selection Harness – 6
Select, Left
Connects the selection buttons to the
control board
N/A N/A X X
1122777
Selection Harness – 3
Select, Right
Connects the lights to the control board N/A X N/A N/A
1122778
Selection Harness – 3
Connects the selection buttons to the
N/A X N/A N/A
1124876 Display Harness HVV
Connects the display to the control
board
N/A X X X
1122193
Connects the evaporator fans to the
power distribution box
X X X X
1123075
Evaporator Fan
Harness HVV
Connects the evaporator fans to the
power distribution box
N/A X X X
1123444
Power Distribution
Harness
Input for 110v service cord and output to
compressor, evaporator, fans, control
X X X X
1124065
Motor Harness w/
Pre-cool – 10 Select
Connects the vend motors to the door
harness
N/A N/A X X
Connects the vend motors to the door
V21 Cabinet Parts | C-20
