SandenVendo V21 621 - Page 121

V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230336
Pre-cool – 8 Select
harness
1124864
Live Display Lighting
Harness
Connects the lights to the control board X X X X
1087309
Live Display Selection
Harness – 10 Select
Connects the selection buttons to the
control board
N/A N/A X N/A
1126871
Live Display Selection
Harness – 8 Select
Connects the selection buttons to the
control board
N/A X N/A N/A
1126872
Live Display Read-to-
Vend/Sold out
Harness
Connects the vend motors to the door
harness
N/A X X N/A
1124570 MDB Harness
Connects the coinage to the control
board
X X X X
1204014
LED Power
Connects the three LED lights to power
N/A
N/A
X
X
1204233
LED RELAY
Connects the LED lights to door switch
N/A
N/A
X
X
1123679
Lock System Harness
HVV
Connects the electronic lock to the
control board
N/A X X X
1122609
Upper Lights Harness
HVV
Connects the upper lights to the lower
lights
N/A X X X
1123320
Lower Lights Harness
HVV
Connects the lower lights to the ballast N/A X X X
1229206
Light Harness T8
Complete
Chameleon
Connects the lights to Power Box X N/A N/A N/A
1225426
Light Harness T8
Complete Chameleon
Connects the lights to Power Box N/A X N/A N/A
1225417
Light Harness T8
Complete
Chameleon
Connects the lights to Power Box N/A N/A X X
1204014
Light Harness T8
Complete HV3
Connects the lights to Power Box N/A X X X
1225408
Light Harness T8
Complete HVV
Connects the lights to Power Box N/A X X X
1225435
Light Harness T8
Complete Trade
Connects the lights to Power Box N/A X X N/A
1225417
Light Harness T8
Complete Trade
Connects the lights to Power Box N/A N/A N/A X
1124864
Light Harness T8
Complete
Trade Live Display
Connects the lights to Power Box N/A X X N/A
1124865
Light Harness T8
Complete
Trade Live Display
Connects the lights to Power Box N/A X N/A N/A
V21 Cabinet Parts | C-21
