V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230417
HV3 DOOR (CONTINUED)
ITEM
NO.
MODEL NUMBER 721 821
HARDWARE
DESCRIPTION
QTY
REQ
PART
NO.
QTY
REQ
PART
NO.
1
HINGE - INNER DOOR,
MALE
2 1121287 2 1121287 F
2
FLUSH MOUNTING
BRACKET
- CONTROLLER
1 1202557 1 1213677 H
3 STAND OFF 7 1121740 7 1121740
4
PCBA VEC 12.1
CONTROLLER
1 1167867 1 1167867
5 PCBA COVER PANEL 1 1123049 1 1123049 H
6 PLATE, DBV PLUG, UPPER 1 1143498 1 1143498 F
7 COIN INSERT CHUTE 1 1121066 1 1121066 U
8 ASY, COIN RETURN LEVER 1 1182651 1 1182651 F
9 DOOR BUMPER 2 1036912 2 1036912
10
DELIVERY HOPPER
ASSEMBLY
1 1189115 1 1189115 D,K
11 RAIN GUTTER 1 1121204 1 1121204 K
12
PNL, SHR, UPR/LWR,
39" 4-BLB
2 1204361 2 1204361 K
13 COIN BOX
1
1088058
1
1088058
14
COIN CHUTE COVER
1
1181555
1
1181555
15 ASY,LED LIGHT FIXTURE 1 1198967 1 1198967
NOTE: FOR A COMPLETE LIST OF HARNESSES, PLEASE SEE PAGE C-15.
NOTE: (NP) – NOT PICTURED
*EARLY PRODUCTION AND INTERNATIONAL UNITS (PRE-2011)
V21
Door Parts HV3 ADA | D7-5
