V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230255
Set Depth:
This Mode allows you to set the depth of each column. In this mode, you have the option of
setting the columns for single, double, triple or quadruple depths.
1. When display reads “Set Depth” press Button 4.
2. Press Button 2 or 3 to choose columns or “All.”
3. Press Button 4 to enter into the column and start the depth flashing.
4. Press Button 2 or 3 to scroll through the depth settings (1-4).
5. Press Button 4 to save your new depth setting.
6. Press Button 1 to exit mode.
Configuration:
There are various options that you can turn ON/OFF. Options underlined are factory default.
Multi-Price
ON - All selections can be programmed individually.
OFF - All selections will be set to the same price as Selection 1.
Timing Features*
ON - Gives you access to the “Clock” settings and its associated modes.
OFF - “Clock” settings and its associated modes are hidden.
Door Summary
ON - Sales and cash data are displayed as soon as the outer door is opened or by
activating the door switch.
OFF - Sales and cash data are not displayed when the door is opened.
MIS Auto Reset
ON - Resets if the counter is checked and after the door is closed.
OFF - Does not reset.
Consumer Overpay
ON - A dollar bill will be accepted even if the correct change light is on and there is
insufficient change in the coin tubes.
OFF - A vend will not be allowed when the correct change light is on and the consumer
attempts to use the dollar bill validator.
Save Credit Timer
ON - Credit that is established will be displayed for five minutes unless someone either
makes a vend or presses the coin return button - whichever comes first.
OFF - Credit that is established will remain indefinitely unless someone either makes a
vend or presses the coin return button.
Force Vend
ON - The consumer will not be able to insert a dollar into the validator, hit the coin return
V21 12.4 Programming HV3 / CHAMELEON | P1-6
