TECHNICAL PARAMETERS
The recovery unit is classifi ed as a Class II product.
The degree of protection is IPX4.
The recovery unit has been designed to be installed in closed places. The operating temperatures are between -20°C and
50°C with maximum relative humidity 80%.
The design of the recovery unit is constantly evolving, therefore, certain models could differ from that detailed in this ma-
nual.
RESPIRO 100 / RESPIRO 100 RD
RESPIRO 100
Speed 1 2 3
Voltage at 50Hz 220-240 Vac 220-240 Vac x
Power [W] 3,9 7,9 x
Capacity [m³/h] 15 30 x
Noise at 3 m [dB] 19 29 x
Max heat recovery 93% 93% x
Average heat recovery 70% 78% x
RESPIRO 100 RD
Speed 1 2 3
Voltage at 50Hz 220-240 Vac 220-240 Vac 220-240 Vac
Power [W] 3,9 5,9 7,9
Capacity [m³/h] 15 22,5 30
Noise at 3 m [dB] 19 24 29
Max heat recovery 93% 93% 93%
Average heat recovery 70% 74% 78%
