DIAGRAMA DE CONEXIÓN
10
Capacitor
Marrón (Cable del Motor)
Negro (Cable del Motor)
Azul (Cable del Motor)
Amarillo/Verde
(Cable del Motor)
Controlador Velocidad del Motor
Sin Controlador de Velocidad del Motor
Negro
Marrón
Amarillo/Verde
Azul
MOTOR
120 VAC 60Hz
Tierra
Neutro
Negro
Marrón
Amarillo/Verde
Azul
MOTOR
Entrada
120 VAC 60Hz
Tierra
Neutro
Entrada
Motor
Regolador
de
Velocidad
