4. PARTS LIST/REFERENCE
Before starting installation, check to make sure all parts are present in package.
Primary Components
Base Plate (1) Water Pump (1) Filter Tank (1)
7 Position Multi-Port Valve (1) Manifold (1) Spigot
Clamp Ring Assembly (1) Drain Valve Assembly (1) Filter Pump Hose (1)
Threaded Connector with O-Ring (3) Main Tank Seal (1) O-Ring (3): A-2¼" dia, B-3" dia, C-1½" dia
Manifold Tube (1) Rubber Reducer (2) Hose Clamp (2)
Hair & Lint Strainer Cover (1) 1½" - 1¼" Hose Connector (2) Manifold Fingers (6)
Pump Mounting Hardware (2 sets) Threaded Collar (1) 5mm Hex key Owner’s Manual
Note: Some parts may be pre-installed at the factory. Parts not shown to scale.
