Method 1
Raise Right Tray to Slant towards Centre
1. Lift right-hand side tray up.
2. You will feel it click into place.
Method 2
Raise Both Trays to Slant towards Centre
1. Lift right tray.
2. Lift left tray.
3. You will feel both click into place.
Method 3
Double-stack Trays on Left
1. Lift right tray.
2. Slide left, slot into place.
3. You will feel the tray click into place.
Method 4
Remove Right Tray
1. Life right tray.
2. Slide left and up, lift out.
Method 5
Raise Right Tray 1 Level, Keep Horizontal
1. Lift right tray.
2. Slide left and up.
3. Slide back to the right.
4. You will feel it click into place.
Method 6
Remove Cutlery Drawer
1. Remove the entire basket by pulling towards you and lifting out.
