6
Product Overview
Front View
1. Speakers
2. Remote Control Sensor
Receives signal from the remote
control.
3. Status Indicator
• Unlit when the unit is in STANDBY
mode.
• Lights up red in iPod mode.
• Lights up green in AUX mode.
• Lights up blue in Bluetooth
® mode.
1
2 3
1
Rear View
1. AUX IN Socket
Connects to an external audio device.
2. AC INPUT Socket
Connects to the mains socket with the
mains cable.
AUX IN
AC INPUT ~
1 2
SSDKBT13_IB_130506_Zell.indd 6 6/5/13 1:45 PM
