To speed up the programming sequence you can copy one day into
another, or several other days.
Press Set x2 to enter copy mode.
Choose the 'Copy' day using＋and press Ok.
Choose the 'Paste' day using＋and press Ok.
Repeat step as required for further 'Paste' days.
At any point Press Ok x2 to return to Run Mode.
2
Health & Safety
Regulations.
proceeding.
may be subject to change without prior notice.
Health & Safety
This unit must be installed by a suitably qualified person in accordance with the latest IEE Wiring
Regulations.
Isolate mains supply before commencing installation. Please read all installation instructions before
proceeding.
Example circuit diagrams for typical installations are shown. These diagrams are schematic and should
be used as a guide only. Please ensure that all installations comply with the current IEE regulations. For
reasons of space and clarity not every system has been included and the diagrams have been simplified,
for instance some Earth connections have been omitted. Other control components shown in the
diagrams i.e. Valves, Room Stats etc. are general representations only. However, the wiring detail can
be applied to the corresponding models of most manufacturers.
Your product is not user serviceable. Do not dismantle this product.
Due to our policy of continuous product improvement and development, the specifications in this guide
may be subject to change without prior notice.
Elite Security Products
Unit 7, Target Park, Shawbank Road,
Lakeside, Redditch, B98 8YN
Tel: 01527 515150
Fax: 01527 515143
Email: info@espuk.com
Web: www.espuk.com
4. COPY/PASTE DAY:
To manually change the temperature temporarily you simply press
the raise or lower buttons to the desired level, if left alone this will
stay set until the next programmed change at which point it returns
back to the original schedule.
Choose desired temperature using＋－and press Ok.
To cancel setting early and return to normal operation press Ok.
5. CHANGE THE TEMPERATURE:
You can also set the thermostat to hold at the temperature you want
for a defined number of hours.
Press M to enter override mode then select temperature using＋－
and press Ok.
Select number of hoursusing＋－(max 23 hours) and press Ok.
Comfort Override, Temp. Set & Hours, with the hours remaining,are
shown on the display.
To cancel setting and return to normal operation press Ok.
6. CHANGE THE TEMPERATURE FOR A SET NUMBER OF HOURS:
Hold the thermostat at a desired temperature until manually
cancelled by you.
Press M x2 to enter permanent override mode then select tem-
perature using＋－ and press Ok.
Permanent Hold and Temp. Set are displayed.To cancel setting
and return to normal operation press Ok.
7. HOLD TEMPERATURE PERMANENTLY:
Hold the temperature at a desired set point until a specific date.
Press M x3 to enter holiday mode then select temperature using＋－
and press Ok.
Select the Month and Year using＋－and press Ok.
Select the Day using＋－and press Ok.
Hold Temp Until, Temp. Set & Hours are displayed.
To cancel setting and return to normal operation press Ok.
To erase all current settings and return to it’s factory default settings
& programs.
Press and hold Ok and－for 6 seconds.
When Reset is displayed push in the Reset button.
All segments on the display are shown to confirm reset has taken
place.
8. HOLIDAY MODE:
9. RESET UNIT:
Date Issued
J20 A30-CHPRSTATDP-01-2 Rev.1
