Santa Fe Advance2 Installation & Operation Instructions www.Santa-Fe-Products.com | 1-800-533-7533
Ducting To Finished Areas (Optional)
Attaching Duct Collars
Return Air Inlet
An 10" diameter duct collar and a front panel are attached to the unit.
Supply Air Outlet
Two 10" diameter duct collars attach to the outlets on each side of the unit. They can be attached to one exhaust outlet
or both exhaust outlets. Use the included duct plate to block off one of the outlets if needed.
Input of
Humid Air
Output of
Dehumidified Air
Front View
