Edition du 04-2005 Page 24
Disassembly and assembly of knife and filler
Sheet N° 5
½
Ingredients : Tools :
- None - None
Preliminary Steps:
- Stop the machine with the “Pause”button, squeezers in upper position
- Unplug the machine
- Unlock and open the door.
Operating procedure:
- Removal :
- Follow the preliminary steps
- On models before 1993 : unscrew the black nut (1)
- Slightly pull knife to the front, so as to bring holes (3) in plates (4) in front of pines (5)
- Lift and remove complete knife
- Remove filler (6) located in the tank bottom
- Installation:
- Correctly install filter (6) in the tank bottom.
- Engage slot (7) of plate (4) under black knurled nut (1) (on models before 1993), bring
holes (3) inplates (4) in front of pines (5)
- Push knife (2) fully to the rear
- Tighten knurled nut (1) (on models before 1993)
