Installation and relmoval of the cones
Sheets N° 6 ½
Ingredients : Tools :
- None - None
Preliminary Steps:
- Stop the machine using the “pause” button (squeezing uppper position)
- Unplug the machine
- Unlock and open the door
- Remove the knife (see sheet n°5)
Operating procedure:
- Removal
- Follow the preliminary steps
- Lift each cone (1 and 2) in order to separate them from their respective shaft inside the
tank
- Remove each cone from the machine
- Separate each cone (3) from its respective base (4)
- Separate spring (7) and ejector from each cone (3)
- Installation
- Install spring (7) and ejector (8) on each cone (3)
- Place each cone (3) on its base (4)
- Insert 6 pins (3) into corresponding holes (6) in the base by simply pressing.
