Parts: Check carefully to make sure all parts listed are not missing or damaged!
(1) Universal Projector Interface - a (2) Extension Arm - b
(1) Ceiling Plate - c (1) Adjustment Bracket - d
(2) Bottom Cover - e (2) Top Cover - f
(4) M3 x 10 mm - g (4) M4 x 12 mm - h (4) M5 x 12 mm - i (4) M6 x 12 mm - j
(2) M6 x 8 mm - k (2) Button Head Cap Screw - l (1) Set Screw - m (4) Tapered Nut - n
(1) Allen Key - o (4) M3/M4 Washer - p (4) M5/M6 Washer - q (2) Lag Bolt Washer - r
(1) Allen Key - s (2) Lag Bolts - t
