2
Spacer: 16mm
Spacer: 2.5mm
M4 x 30mm
Horizontal
Bracket
Arm
Bracket A
Arm
Bracket B
Bottom Bracket
M6 x 30mm
M4 x 50mm
M8x30 mm
M6 x 50mm
M8 x 40mm
M8 x 50mm
M8 x 65mm
M4 Washer
M4 / M5 Washer
M8 /M6 Washer
Interface Washer
M4 x 10mm
M4 x 16mm
M5 x 16mm
M6 x 16mm
Key Hole Screw
(1/4-20)
Knob
M6 Washer
UL/TUV Certified
TV Wall Mount *
*Your TV wall mount may vary from the
illustrations throughout this manual.
NOTE that the procedure to install the
soundbar is the same.
Phillips Screwdriver
Level
NOTE: Not all hardware included will be used.
WARNING:
This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If
any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts!
01
02
03
04
08
09
12
13
QTY.1
QTY.1
QTY.1
QTY.2
QTY.2
QTY.2
QTY.2
QTY.2
Your TV Mount
Manual
TV Screws (qty. 4 each)
[Only one size fits your TV]
Soundbar Screws (qty. 2 each)
[Only one size fits your Soundbar]
Washer
(qty. 4 each)
Soundbar Washers
(qty. 2 each)
Spacer
[If necessary]
(qty. 4 each)
05
10 11
06 07
M4
M4 M5
M6
M6
M8
PARTS INCLUDED
Items Needed
To Next Page
