- 26 -
No. Part Name Service Code Q'Ty Specification
30
Top Plate 6 17 - 259 - 9700 1 202N
31
SCR TPG TRS 4x12 411 - 074 - 5806 2
32
SCR TPG TRS 4x20 411 - 007 - 1004 2 FIX TOP PLATE
33
SCR TPG TRS 4x10 411 - 074 - 5004 4 FIX FRAME ATTACH
34
Tab Housing Ass y 617 - 245 - 6614 1 220 - 240V
35
Tab Housing Ass y 617 - 250 - 2557 1 220 - 240V, M3 IEC
35.1
Fuse Ass y 617 - 244 - 1061 1
36
Back Plate 617 - 259 - 9731 1 202N
38
Sub Drain Cap 617 - 259 - 9779 1 P.P
39
Soap Box Ass'y 617 - 245 - 9219 1
40
Frame Complete 617 - 259 - 6976 1
41
Frame Attach 617 - 243 - 8061 1 PP. TPC AR564 (RIGHT)
42
Frame Attach 617 - 263 - 6672 1 PP. (LEFT)
43
Front Panel 617 - 259 - 7089 1 T0.5 (PCM)
44
Spring Damper Base 617 - 180 - 4676 4 P.P
45
Stopping Pin 617 - 261 - 0092 4 SUS - 304 - WPB D2.0
46
SCR TPG TRS 4x14 411 - 074 - 6605 2
47
Frame Handle 617 - 262 - 7809 2 P.P NATURAL
48
Drain Hose Ass y 617 - 252 - 5853 1 INNER
49
Hose Band 617 - 026 - 4891 1
50
Drain Hose Ass y 617 - 155 - 7879 1 OUTER
51
Leg 617 - 259 - 7096 1 AR564 - COOL GRAY 10C
52
Bottom Cover 617 - 259 - 8345 1 P.P
53
SCR TPG TRS 4x14 411 - 074 - 6605 7
54
Cushion 617 - 180 - 4423 3
55
SCR TPG TRS 6x20 411 - 149 - 5106 3
56
Adjustor Screw 617 - 180 - 4386 1 FRPP E - 7000
57
Adjustor Cap 617 - 263 - 6955 1 COOL GRAY
58
Adjustor 617 - 183 - 6363 1
59
Drain Cap 617 - 262 - 7830 1 PP COOL GRAY
60
Lead Stay 617 - 021 - 1413 1
61
Cord Ass y 617 - 231 - 4624 1 M3
62
Cord Stay 617 - 021 - 1338 1 NYLON
63
SCR TPG TRS 4x12 411 - 074 - 5806 1
64
Capacitor Ass y 617 - 230 - 3550 1 444V.AC 8.0MF
65
Sound Proof Board 617 - 025 - 3635 3
