-7-
IC Block Diagrams
Service Information
This TV set has a built-in power supply protection circuit.
It is provided to protect the TV set in case of a power supply circuit malfunctions. When something abnormality
occurs during TV reception, the TV set goes to the stand-by mode.
When an abnormality occurs during TV reception, it causes pin 27 of the CPU to go continually Low(less than
0.75V) for about one second. The CPU detects that this has occurred and outputs the signal from pin 31 to
switch off the power supply lines.
Releasing the protective circuit and restoring power supply
To release the protective circuit and restore power supply, turn the power to the TV set OFF and then ON again
via either the main power switch or the ON-OFF button on the remote control. This will work only if the power
supply trouble was temporary. If there is permanent trouble such as a damaged circuit, power cannot be
restored and the circuit will have to be repaired.
Protection Circuit
IC501 < Vertical Output > LA78040/TDA9302H
Thermal
Protection
-
+
AMP
Pump
Up
1
INVERTING
INPUT
2
Vcc
3
PUMP UP
OUT
4
GND
5
Ver. OUTPUT
6
OUTPUT
STAGE Vcc
7
NON INV.
INPUT
IC002 < Audio AMP.> LA4267
12
34
5
6
7
8
9
10
NC NC
Filter PRE
GND
IN2
300
30k
NF2
OUT2
Power
GND
VCC NC
10
9
Pulse
DET
Pulse
I/F
Clamp
VCO
SW2
11
Filter
PLL
DET
12
13
System
SW1
LIM
KILLER
Bell/EQU
Filter
SW3
1415
ACC
Bell/EQU
Adj
16
1
2
3
ID-KIL
ID
4
5
F0 Adj
6
7
SW/ALC
8
F0-Fil Kil-Fil
4.43DC ID-Fil 4M-DC
R-Y Out
B-Y Out GND
4MHz InSC-In
4.43MHz In
AV/SECAMKil-Out
Video In
VccEQU-Adj
IC281 <SECAM Decoder> LA7642N
SM_14-C4FVR(RU) 1/6/05 2:23 PM Page 7
