Service Manual SM CE29FFV1-F
Ref. No. Part No. Description Ref. No. Part No. Description
6
14. PARTS LIST
PCB SOCKET TRC
CON_FD 0160220729 Polarized Band 4P 520+6+6
CON_FH 0160230819 Polarized Band Gray 5P. 450+6+6
CAPACITORS
C500 0270341324 Polyester 100 nF. 10% 250V.
C501 0250322815 Electrolytic 10 µF. 250V.
C503 0240590901 Ceramic 2200 pF +80-20% 2KV.
DIODES
D500 0360007215 BAV21 DIODE
D501 0360007215 BAV21 DIODE
D502 0360007215 BAV21 DIODE
E500 0640705117 Eyelet 2,5-3
FD1 0330144205 Ribbon Wire Holder 4 P.
FH1 0330144304 Ribbon Wire Holder 5 P.
FK 0640300604 Earth Wire 340 mm.
INTEGRATED CIRCUITS
IC500 0360514210 TDA 6107 Q/N2
J117 0470040007 Jumper Lead 0,6 mm.
L502 0090304924 Choke R.F. 470 µH. 10%
L506 0090208307 Coil 75 µH. 10% 1,5 A. R-7,5
PCB04
0750153520 Socket PCB 5-C
RESISTORS
R500 0790741409 Solid 1,5 KΩ 10% 1/2W.
R501 0790741409 Solid 1,5 KΩ 10% 1/2W.
R502 0790741409 Solid 1,5 KΩ 10% 1/2W.
R503 0790741409 Solid 1,5 KΩ 10% 1/2W.
R504 0790741409 Solid 1,5 KΩ 10% 1/2W.
R505 0790239008 R.M.G. SMD 1 KΩ T<=5% 0805
R506
0790535702 Fuse 10 Ω 5% 0,33W.
R507 0790227003 R.M.G. SMD 100 Ω T<=5% 0805
R508 0790227003 R.M.G. SMD 100 Ω T<=5% 0805
R509 0790227003 R.M.G. SMD 100 Ω T<=5% 0805
R510 0790242002 R.M.G. SMD 1,8 KΩ 5% 1/10W.
R511 0790242002 R.M.G. SMD 1,8 KΩ 5% 1/10W.
R512 0790242002 R.M.G. SMD 1,8 KΩ 5% 1/10W.
ZOCALO
0330162108 Socket TRC Diameter 22,5 mm.
MAIN PCB
CN_FR 0330192402 3P. Connector
CN_G2 0640706503 Blue G2 Wire with two terminals
CN_KV 0330272204 2P. Connector Shield cable 400MM
CN_NA 0330193608 4P. Connector
CN_NB 0330198706 10 P. Connector
CN_NC 0330196601 7P. Connector
CAPACITORS
C100 0230600702 Ceramic SMD 100 nF. 10% 25V.
C102 0230600702 Ceramic SMD 100 nF. 10% 25V.
C103 0230360604 Ceramic SMD 1000 pF. 10% 50V.
C104 0250321072 Electrolytic 10 µF. 63V.
C105 0230480808 Ceramic SMD 10 nF. 10% 50V.
C1051 0250321072 Electrolytic 10 µF. 63V.
C1052 0230600801 Ceramic SMD 100 nF. +80-20% 25V.
C1053 0230480808 Ceramic SMD 10 nF. 10% 50V.
C1054 0230480808 Ceramic SMD 10 nF. 10% 50V.
C1055 0230600702 Ceramic SMD 100 nF. 10% 25V.
C1056 0230600801 Ceramic SMD 100 nF. +80-20% 25V.
C1057 0230600801 Ceramic SMD 100 nF. +80-20% 25V.
C106 0270101322 Polyester 1000 pF. 5% 400V.
C107 0230480808 Ceramic SMD 10 nF. 10% 50V.
C108 0230180309 Ceramic SMD 33 pF. 1% 50V.
C109 0230180309 Ceramic SMD 33 pF. 1% 50V.
C112 0230600801 Ceramic SMD 100 nF. +80-20% 25V.
C113 0230360604 Ceramic SMD 1000 pF. 10% 50V.
C114 0230360604 Ceramic SMD 1000 pF. 10% 50V.
C115 " 0230360604 Ceramic SMD 1000 pF. 10% 50V.
C116 " 0230360604 Ceramic SMD 1000 pF. 10% 50V.
C118 0230360604 Ceramic SMD 1000 pF. 10% 50V.
C120 0230480808 Ceramic SMD 10 nF. 10% 50V.
C1251 0230720203 Ceramic SMD 1 µF. 16V. +80-20% 0805
C1252 0230600702 Ceramic SMD 100 nF. 10% 25V.
C190 0230600702 Ceramic SMD 100 nF. 10% 25V.
C191 0230640401 Ceramic SMD 220 nF. 10% 16V.
C200 0250321072 Electrolytic 10 µF. 63V.
C201 0230360604 Ceramic SMD 1000 pF. 10% 50V.
C202 0230360604 Ceramic SMD 1000 pF. 10% 50V.
C203 0230600702 Ceramic SMD 100 nF. 10% 25V.
C204 0230600702 Ceramic SMD 100 nF. 10% 25V.
C207 0250321072 Electrolytic 10 µF. 63V.
C209 0230480808 Ceramic SMD 10 nF. 10% 50V.
C210 0230600801 Ceramic SMD 100 nF. +80-20% 25V.
C250 0230600801 Ceramic SMD 100 nF. +80-20% 25V.
C251 0250461217 Electrolytic 100 µF. 25V.
C252 0270341480 Polyester 100 nF. 10% 63V.
C256 0230480808 Ceramic SMD 10 nF. 10% 50V.
C257 0270341480 Polyester 100 nF. 10% 63V.
C258 0230480808 Ceramic SMD 10 nF. 10% 50V.
C259 0230600801 Ceramic SMD 100 nF. +80-20% 25V.
C260 0250410859 Electrolytic 47 µF. 25V.
C261 0230600801 Ceramic SMD 100 nF. +80-20% 25V.
C300 0250572310 Electrolytic 1000 µF. 25V.
C301 0230600702 Ceramic SMD 100 nF. 10% 25V.
C302 0230360604 Ceramic SMD 1000 pF. 10% 50V.
C303 0230360604 Ceramic SMD 1000 pF. 10% 50V.
C304 0230640401 Ceramic SMD 220 nF. 10% 16V.
C305 0230640401 Ceramic SMD 220 nF. 10% 16V.
C306 0230640401 Ceramic SMD 220 nF. 10% 16V.
C307 0230640401 Ceramic SMD 220 nF. 10% 16V.
C308 0250321072 Electrolytic 10 µF. 63V.
C309 0250321072 Electrolytic 10 µF. 63V.
C310 0240551309 Ceramic 1000 pF. 10% 50V.
C311 0270341324 Polyester 100 nF. 10% 250V.
C312 0270341324 Polyester 100 nF. 10% 250V.
C352 0250410859 Electrolytic 47 µF. 25V.
C353 0250410859 Electrolytic 47 µF. 25V.
C354 0230600801 Ceramic SMD 100 nF. +80-20% 25V.
C355 0230600801 Ceramic SMD 100 nF. +80-20% 25V.
C356 0250500618 Electrolytic 220 µF. 16V.
C357 0250461217 Electrolytic 100 µF. 25V.
C359 0230480808 Ceramic SMD 10 nF. 10% 50V.
C361 0250461217 Electrolytic 100 µF. 25V.
C362 " 0230160400 Ceramic SMD 22 pF. 1% 50V.
C363 " 0230160400 Ceramic SMD 22 pF. 1% 50V.
C364 " 0230240400 Ceramic SMD 100 pF. 5% 50V.
C365 " 0230240400 Ceramic SMD 100 pF. 5% 50V.
C400 0250461217 Electrolytic 100 µF. 25V.
C401 0230600801 Ceramic SMD 100 nF. +80-20% 25V.
C402 0230740003 Ceramic SMD 2,2 µF. 10V. +80-20%
C403 0230520504 Ceramic SMD 22 nF. 10% 50V.
C404 0230640401 Ceramic SMD 220 nF. 10% 16V.
C405 0230360604 Ceramic SMD 1000 pF. 10% 50V.
C406 0230600702 Ceramic SMD 100 nF. 10% 25V.
C407 0230740003 Ceramic SMD 2,2 µF. 10V. +80-20%
C408 0230600702 Ceramic SMD 100 nF. 10% 25V.
C409 0230600702 Ceramic SMD 100 nF. 10% 25V.
C410 0230600702 Ceramic SMD 100 nF. 10% 25V.
C411 0230180309 Ceramic SMD 33 pF. 1% 50V.
C412 0230180309 Ceramic SMD 33 pF. 1% 50V.
C413 0230740003 Ceramic SMD 2,2 µF. 10V. +80-20%
C414 0230520504 Ceramic SMD 22 nF. 10% 50V.
C415 0250461217 Electrolytic 100 µF. 25V.
C416 0230520504 Ceramic SMD 22 nF. 10% 50V.
C417 0230400202 Ceramic SMD 2200 pF. 10% 50V.
C418 " 0230240400 Ceramic SMD 100 pF. 5% 50V.
C419 " 0230200503 Ceramic SMD 47 pF. 5% 50V.
C420 0230680308 Ceramic SMD 470 nF. 10% 16V.
C421 0230440406 Ceramic SMD 4700 pF. 10% 50V.
C422 " 0230240400 Ceramic SMD 100 pF. 5% 50V.
C423 " 0230360604 Ceramic SMD 1000 pF. 10% 50V.
C424 " 0230520504 Ceramic SMD 22 nF. 10% 50V.
