Pin No Function Name Function In/Out
65 SVM Scan Velocity Modulation Out
66 FbiSo Flyback In SandCastle Out In/out
67 Hout Horizontal Drive Out Out
68 VssComb Gnd
69 V5Comb 5v Supply --
70 Vin/R2/Pr Scart 2 R-In In
71 Uin/B2/Pb Scart 2 B-In In
72 Yin/G2/Y Scart 2 G-In In
73 Y Sync Y Sync In
74 Y out Yout Out
75 Uout/Fb in Scart 2 Fast Blanking In
76 Vout/Sw01 --
77 Fbl3 Scart 1 Fast Blanking In
78 R3/Pr Scart 1 R-In In
79 G3/Y Scart 1 G-In In
80 B3/Pb Scart 1 B-In In
81 Gnd 3 Gnd --
82 V5P3 5vSupply --
83 BCL Beam Current Limiting In
84 Iblack --
85 Rout Red Drive Out
86 Gout Green Drive Out
87 Bout Blue Drive Out
88 V3.3A1 3.3v Supply --
89 RefAdn Ref Gnd --
90 V3.3RefAdp 3.3v Supply --
91 RefAd --
92 GndA Gnd --
93 V1.8A 1.8v Supply --
94 V3.3A2 3.3v Supply --
95 VssAdc Gnd --
96 V1.8Adc 1.8v Supply --
97 Into Remote control In In
98 P10/Int1 SCl In/out
99 P121/TO SDA In/out
100 V1.8C2 1.8v Supply --
101 VssC2 Gnd --
102 P04/I2Sws --
103 P03/I2SCLk --
104 P02/I2SDOC --
105 P01/I2SDOC --
106 P00/I2SDi1 StandBy Out
107 P13/T1 On/Off Out
108 P16/SCL SCL In/out
109 P17/SDA SDA In/out
110 V3.3P 3.3v Supply --
111 P20/Tpwm Relay On/Off Out
112 P21/Pwmo LED Drive Out
113 STATUS Status In/out
114 ALK Alk In/out
115 P30/Adco Scart 1 Pin8 Function In
116 P31/Adc1 Scart 2 Pin8 Function In
117 V1.8C1 1.8v Supply --
118 DecV1v8 1.8v Supply --
119 P32/Adc2 AGC In
120 P33/Adc2 Key scan in In
121 VssC1+P1 Gnd --
122 P24/Pwm3 Audio Mute Out
123 P25/Pwm4 L/L’ switch (Export only) Out
124 V1.8C3 1.8v Supply --
125 Vssc3 Gnd --
126 P12/Int2 --
127 P14/Rx Power Fail In
128 P:15/Tx Natural Wide Switch
