Pin No Function Name Function In/Out
1 VSS Gnd --
2 VSS Gnd
3 1v8_1 1.8v Supply --
4 3v3 3.3v Supply --
5 Vref 3.3v Reference --
6 Vref V Ref Gnd --
7 Vref 3.3v Reference --
8 Vref V Ref Gnd --
9 Vref 3.3v Reference --
10 XTAL IN Clock Oscillator In
11 XTAL OUT Clock Oscillator Out
12 Vss Gnd --
13 Vguard sw --
14 Dec Dig 1.8v source supply Out
15 5v 5v Supply --
16 Phi 2 Phi 2 --
17 Phi 1 Phi 1 --
18 Gnd Gnd --
19 Sec pii --
20 Dec BG --
21 EW Drive parabola out Out
22 VdrB Vertical drive B Out
23 VdrA Vertical drive A Out
24 Vif 1 Vision IF 1 In
25 Vif 2 Vision IF 2 In
26 Vsc --
27 I Ref Reference current --
28 Gnd Gnd --
29 Sif 1 Sound IF 1 In
30 Sif 2 Sound IF 2 In
31 Agc Auto matic gain control In
32 Eht Eht In
33 SSif/Ref Iin/Avl/Ref Out --
34 Audio in Scart L In
35 Audio in Scart R In
36 Audio Out Scart L Out
37 Audio Out Scart R Out
38 --
39 Qsso/Amo/AudioEm --
40 Gnd --
41 PLL IF Phase Lock Loop If --
42 SifAgc SifAgc --
43 IFVo Scart 1 Video Out
44 FmRo --
45 V8Audio Switches --
46 AgcsSif --
47 V5P2 5v Supply --
48 Svo/IfVo/Cbvs1 Scart 2 Video Out
49 Audio4 L In Scart 2 Audio L In
50 Audio4 R In Scart 2 Audio R In
51 Y4/Cvbs4 Av3 Video In
52 C4 --
53 Audio2InL Av3 Audio L In
54 Audio2InR Av3 Audio R In
55 Cvbs2/y Scart 1 Video In
56 Audio3InL --
57 Audio3InR --
58 Y3/Cvbs Scart 2 Video In
59 C3 Scart 2 Chroma In In
60 Audio Out L SL Audio out Left Speaker Out
61 Audio Out L SR Audio Out Right Speaker Out
62 Audio Out HPL Scart Audio L Out 2 / monitor Out Out
63 Audio Out HPR Scart Audio R Out 2 / monitor Out Out
64 Pip --
