C7ZES
-19-
CHASSIS ELECTRICAL PARTS LIST
Product safety should be considered when a component replacement is made in any area of a receiver.
Components indicated by a mark in this parts list and the circuit diagram show components whose value have
special significance to product safety. It is particularly recommended that only parts specified on the following
parts list be used for components replacement pointed out by the mark .
013C7ZES ELECTRICAL PARTS
COIL
L901 645 067 8813 DEGAUSS 32" W/F SAMSUNG
PICTURE TUBE
Q901 414 012 8907 CRT W76QEN693X005 SAMSUNG
MISCELLANEOUS
SP901 645 047 2046 SPEAKER 8 H125/1039
SP902 645 047 2046 SPEAKER 8 H125/1039
W901 645 012 7632 EURO PLUG +2P HOUSE @ 2.1
W902 610 316 0351 GND CON.EB8A 32" C7YAV
W902A 610 206 0300 GROUNDING SPRING-S4LA
W902B 610 079 4085 GROUNDING SPRING-F
1AA0B10H075CA ASSY,PWB,MAIN C7ZES
CAPACITOR
C003 403 314 5915 GRM21BR71C474KA01L PT297
C004 403 314 5915 GRM21BR71C474KA01L PT297
C005 403 215 2310 GRM188R71H123KA01D PT115
C006 403 215 2310 GRM188R71H123KA01D PT115
C011 403 269 5916 GRM219R71C224KC01D PT115
C012 403 269 5916 GRM219R71C224KC01D PT115
C013 403 269 5916 GRM219R71C224KC01D PT115
C014 403 269 5916 GRM219R71C224KC01D PT115
C015 403 269 5916 GRM219R71C224KC01D PT115
C016 403 269 5916 GRM219R71C224KC01D PT115
C017 403 269 5916 GRM219R71C224KC01D PT115
C018 403 269 5916 GRM219R71C224KC01D PT115
C021 403 047 3100 ELECT 47U M 25V
C022 403 233 0817 ELECT 10U M 50V
C023 403 218 8151 25 YK 1000 M TA 1020
C024 403 157 1914 GRM1885C1H100JZ01
C025 403 153 9112 GRM1885C1H5R0CD01D PT115
C026 403 103 2257 CK45-B1H101KYR TDK 50V
C040 403 113 4119 GRM188R71H222KA01D PT115
C053 403 157 4212 GRM1885C1H221JZ01D PT115
C055 403 157 4212 GRM1885C1H221JZ01D PT115
C057 403 113 3815 GRM188R71H102KA01D PT115
C1001 403 248 1618 16 YK 47 M TA 0511
C1003 403 157 3611 GRM1885C1H101JZ01D PT115
C1005 403 113 3815 GRM188R71H102KA01D PT115
C1006 403 157 3611 GRM1885C1H101JZ01D PT115
C1007 403 113 3815 GRM188R71H102KA01D PT115
C101 403 233 1111 ELECT 22U M 50V
C1011 403 248 1618 16 YK 47 M TA 0511
C1013 403 157 3611 GRM1885C1H101JZ01D PT115
C1014 403 157 3611 GRM1885C1H101JZ01D PT115
C1016 403 113 3815 GRM188R71H102KA01D PT115
C1017 403 113 3815 GRM188R71H102KA01D PT115
Ref. No.
Part No.
Description
Chassis construction
CE32FWN6F-C-00
013C7ZES ELECTRICAL PARTS DIRECTOR (PAGE 19)
1AA0B10H075CA ASSY,PWB,MAIN C7ZES (PAGE 19 - 24)
1AA0B10H075CB ASSY,PWB,SOCKET C7ZES (PAGE 24)
1AA0B10E689AA ASSY,PWB,FRONT-A MAINS (PAGE 24 - 25)
1AA0B10E689AB ASSY,PWB,FRONT-B AV3 (PAGE 25)
Read description in the Capacitor and Resistor as follows:
CAPACITOR
CERAMIC 100P K 50V
Tolerance Symbols:
Less than 10PF
A: Not specified B: ±0.1PF C: ±0.25PF
D: ±0.5PF F: ±1PF G:±2PF
R: ±0.25-0PF S: ±0-0.25PF E: +0-1PF
More than 10PF
A: Not specified B: ±0.1% C: ±0.25%
D: ±0.5% F: ±1% G: ±2%
H: ±3% J: ±5% K: ±10%
L: ±15% M: ±20% N: ±30%
P: +100-0% Q: +30-10% T: +50-10%
U: +75-10% V: +20-10% W:+100-10%
X: +40-20% Y: +150-10% Z: +80-20%
Material:
CERAMIC............Ceramic
MT-PAPER ..........Metallized Paper
POLYESTER ......Polyester
MT-POLYEST ......Metallized Polyester
POLYPRO............Polypropylene
MT-POLYPRO ....Metallized Polypropylene
COMPO FILM......Composite film
MT-COMPO ........Metallized Composite
STYRENE............Styrene
TA-SOLID ............Tantalum Solid
AL-SOLID ............Aluminium Solid
ELECT ................Electrolytic
NP-ELECT ..........Non-polarised Electrolytic
OS-SOLID ..........Aluminium Solid with Organic Semiconductive Electrolytic
DL-ELECT ..........Double Layered Electrolytic
RESISTOR
CARBON 4.7K J A 1/4W
Rated Wattage
Performance Symbols:
A: General B: Non flammable Z: Low noise
Other: Temperature coefficient
Tolerance Symbols:
A: ±0.05% B: ±0.1% C: ±0.25% D: ±0.5%
F: ±1% G: ±2% J: ±5% K: ±10%
M:±20% P: +5-15%
Rated value, ohms:
K: 1,000, M: 1,000,000
Material:
CARBON ............Carbon
MT-FILM ..............Metal Film
OXIDE-MT ..........Oxide Metal Film
SOLID..................Composition
MT-GLAZE ..........Metal Glaze
WIRE WOUND ....Wire Wound
CERAMIC RES....Ceramic
FUSIBLE RES ....Fusible
Rated Voltage
Rated value: P=pico farad, U=Micro farad
Note: Parts order must contain Service Ref. No., Part No., and descriptions.
