— 12 —
POWER UNIT REMOVAL
Remove 9 screws to take the power unit off.
ATTENTION
This PDP TV uses several different kinds of
screws. Using the correct screw is required to
prevent damage.
The gasket is provided to prevent interference
to other radio and television receivers. The
gasket must be returned to its previous position
after servicing.
Lead wires must be redressed to previous posi-
tions after servicing.
MECHANICAL DISASSEMBLY (CONT.)
To Next Page
