Note:The picture of stand installation is just for the reference, please base on the material object for
the real sample.
For model DP58D34, please just follow A - 2, A - 3.
①M5 (5mm) Diameter, Length-12mm (maximum)
②M4 (4mm) Diameter, Length-20mm (maximum)
Base
base unassembled table
stand
Note:Stand base screws
are located in the
literature package.
Mounting screws measurements
DP42D24
DP50E44
DP55D44
DP58D34
DP65E34
DP39D14
Model
①M5 (5mm) Diameter, Length-12mm (maximum)
M5 (5mm) Diameter, Length-16mm (maximum)
②M5 (5mm) Diameter, Length-16mm (maximum)
① ②①
