No. TITLE
INITIAL REFERENCE INITIAL SETUP
RANGE OF DATA FUNCTION
DATA DATA
1 HFR 1E 1E 00~3F Horizontal Frequency
2 AFC 00 00 00, 01 AFC Gain and Gate
3 HP 0E 0E* 00~1F Horizontal Phase (Horizontal Centering)
4 VS 32 50* 00~7F Vertical Size
5 VPO 05 05 00~3F Vertical Position
6 VSP 00 00 00, 01 Vertical Set Up (Sync Sensitivity)
7 VLN 13 15* 00~1F Vertical Linearity
8 CRS 00 00 00~03 Cross B/W
9 GRY 01 01 00, 01 Grey Mode
10 VSC 08 0A* 00~1F Vertical S Correction
11 HBR 03 03 00~07 Horizontal Blanking Right
12 HBL 04 04 00~07 Horizontal Blanking Left
13 CDM 00 00 00, 01 Color Difference Mode
14 VC 07 07 00~07 Vertical Compression
15 RB 00 00 00~FF Red Bias
16 GB 00 00 00~FF Green Bias
17 BB 00 00 00~FF Blue Bias
18 RD 40 40 00~7F Red Drive
19 GD 08 08 00~0F Green Drive Reduction
20 BD 40 40 00~7F Blue Drive
21 SBI 30 30 00~7F Sub Bias
22 OSD 02 02 00~03 On Screen Display Contrast
23 POS 01 01 00, 01 Preshoot Overshoot Switch
24 FLS 01 01 00, 01 Filter System
25 CKO 03 03 00~07 Color Killer operation
26 GYA 00 00 00, 01 G-Y Angle
27 CRG 02 02 00~03 Corring Gain
28 PRE 03 03 00~03 Preshoot Adjust
29 WP 01 01 00, 01 White Peak Limiter 01: OFF 00: ON
30 FSW 00 00 00, o1 Flyback Blanking Switch
31 VBL 00 00 00, 01 Vertical Blanking Switch
32 BSG 01 02* 00~03 Black Stretch Gain
33 BSS 01 01 00~03 Black Stretch Start
34 DCR 01 01 00~03 DC Reset
35 YGM 01 01 00~03 Y Gamma Start
36 CBP 00 00 00, 01 C Bypass
37 AF 01 01 00, 01 Auto Flesh 0: OFF 1: ON
38 BAT 04 04 00~07 Bright ABL Threshold
39 MSD 00 00 00, 01 Mid Stop Defeat
40 ABL 00 00 00, 01 ABL Defeat 0: OFF 1: ON
41 RYA 02 02 00~0F R-Y/B-Y Angle
42 RAD 0F 20* 00~3F RF AGC Delay
43 IAS 00 00 00. 01 IF AGC Switch 0: TV (Normal) 1: AV (IF Gain Minimum)
44 FMM 00 00 00, 01 FM Mute
— 4 —
Table 1. ON-SCREEN SERVICE MENU
When IC802 (EEPROM) is replaced, check the bus data to confirm they are the same as below. The shaded menu should be
checked and be set up or readjusted according to the procedures described in the following pages. Initial Setup Data marked
with an * should be changed from Initial Reference Data. (See page 3 for Initial Bus Data Setup.)
