— 4 —
INITIAL BUS DATA SETUP (Cont.)
16. Select NO. 67 VMD6VMG3SSN (VM Delay / VM Gain / Sync Sep Sens) with ▲ or ▼ key. Adjust the data with number
keys for 22.
17. Select NO. 84 OP2 (Component / V Guide) with ▲ or ▼ key. Adjust the data with + or – key for 20.
18. Select NO. 88 CGR (RF Coring Gain) with ▲ or ▼ key. Adjust the data with + or – key for C0.
19. Select NO. 8A ROV (RF Over Shoot Adjust) with ▲ or ▼ key. Adjust the data with + or – key for 04.
20. Select NO. 8B RPR (RF Pre Shoot Adjust) with ▲ or ▼ key. Adjust the data with + or – key for 20.
21. Select NO. 8D HR (H Display Position) with ▲ or ▼ key. Adjust the data with + or – key for 24.
22. Select NO. 8E SBO (Sub Bright Offset) with ▲ or ▼ key. Adjust the data with + or – key for 04.
23. Press the MENU key to turn off the Service Menu display.
SERVICE ADJUSTMENTS (Cont.)
