Table 1. ON-SCREEN SERVICE MENU (Continued)
SERVICE ADJUSTMENTS (Cont.)
No. TITLE
INITIAL REFERENCE INITIAL SETUP INITIAL SETUP
FUNCTION
DATA HEX DATA HEX DATA BINARY
6C ECB4ECT 33 54* 01010100 E/W Corner Bottom(7~4) E/W Corner Top (3~0)
6D EWS7ETS3HSC 84 84 10000100 E/W Correction Sw(7) E/W Test (5~3) H Size Comp (2~0)
6E ↓↓↓↓Not Used
6F ↓↓↓↓Not Used
80 ATT 07 07 00000111 Attenuation -MTS Input Level (3~0)
81 WDB 20 20 00100000 Wide Band - Low Separation (5~0)
82 SPC 20 20 00100000 Spectral - High Separation (5~3)
83 OPT 80 A0* 10100000 Surround (7) Aspect Ratio (5)
84 OP2 00 20* 00100000 V Guide(7)
85 FLR 00 00 00000000 RF Filter System (2~0)
86 CBR 20 00* 00000000 RF C Bypass (5)
87 CDR 00 00 00000000 RF Count Down Mode (0)
88 CGR 40 40 01000000 RF Coring Gain (6)
89 AFR 00 00 00000000 RF AFC Gain & Gate (6)
8A ROV 0C 0C 00001100 RF Over Shoot Adjust (3~2)
8B RPR 00 00 00000000 RF Pre Shoot Adjust (5~4)
8C CBT 00 08* 00001000 RF C BPF Test (4~3)
8D HR 13 24* 00100100 OSD H Display Position (7~0)
8E SBO 03 05* 00000101 Sub Bright Offset (5~0)
8F DFL 02 02 00000010 YUV Filter System (2~0)
90 DCN 00 00 00000000 YUV Sub Contrast (6~0)
91 DBR 00 00 00000000 YUV Sub Bright (6~0)
92 DCL 00 00 00000000 YUV Sub Color (6~0)
93 DTN 00 00 00000000 YUV Sub Tint (6~0)
94 DSH 00 00 00000000 YUV Sub Sharpness (6~0)
95 DCG 00 00 00000000 YUV Sub Coring (6)
96 DVG 00 00 00000000 YUV Sub VM Gain (5~0)
97 DHS 00 00 00000000 YUV Sub E/W DC (5~0)
98 DRY 06 0B* 00001011 YUV R-Y Offset (3~0)
99 DBY 70 10* 00010000 YUV B-Y Offset (7~4)
9A DYA 00 00 00000000 YUV APF (6)
9B ECN E0 E0 11100000 16:9 Sub Contrast (6~0)
9C EBR 00 00 00000000 16:9 Sub Bright (6~0)
9D ECL 00 00 00000000 16:9 Sub Color (6~0)
9E ETN 00 00 00000000 16:9 Sub Tint (6~0)
9F EVS D4 D4 11010100 16:9 Sub V Size (6~0)
A0 EVP 00 00 00000000 16:9 Sub V Position (3~0)
A1 EEA F8 F6* 11110110 16:9 Sub E/W Amp (5~0)
A2 EET 03 03 00000011 16:9 Sub E/W Tilt (5~0)
A3 EEP FF FF 11111111 16:9 Sub E/W Corner Top (3~0)
A4 EEB 00 00 00000000 16:9 Sub E/W Corner Bottom (7~4)
A5 EUV 00 00 00000000 16:9 Sub V Linearity (4~0)
A6 B16 00 00 00000000 16:9 ABL VTH Sw (5)
A7 EVB 02 60* 01100000 16:9 V Blanking SW (6~5)
A8 DRV
R40 R40 01000000 Red Drive Adjustment (See Note 1.)
R40 R40 01000000 Blue Drive Adjustment (See Note 1.)
– - - - Red Bias Adjustment (See Note 2.)
– - - - Green Bias Adjustment (See Note 2.)
– - - Blue Bias Adjustment (See Note 2.)
