Sanyo DS24424 Service Manual

— 5 —
Table 1. ON-SCREEN SERVICE MENU
When IC802 (EEPROM) is replaced, check the bus data to confirm they are the same as below. The shaded menu should be
checked and be set up or readjusted according to the procedures described in the following pages. Initial Setup Data marked
with an * should be changed from Initial Reference Data. (See pages 3 and 4 for Initial Bus Data Setup.)
No. TITLE
INITIAL REFERENCE INITIAL SETUP INITIAL SETUP
FUNCTION
DATA HEX DATA HEX DATA BINARY
3B SCN 0F 10* 00010000 Sub Contrast (4~0)
3C SCO 1F 15* 00010101 Sub Color (5~0)
3D STI 07 05* 00000101 Sub Tint (4~0)
3E SB 18 18 00011000 Sub Bright (5~0)
3F SSH 00 00 00000000 Sub Sharpness (4~0)
40 AFC6HFR 90 90 10010000 AFC(6) Horizontal Frequency (5~0)
41 HP 12 0F* 00001111 Horizontal Phase (4~0)
42 VS 60 5A* 01011010 Vertical Size
43 VSP7VKI6VDC 07 18* 00011000 V Sync Sep (7) V Kill (6) V DC (5~0)
44 HBL5VLN 06 35* 00110101 H Blanking L (6~5) V. Linearity (4~0)
45 HBR5VST 20 43* 01000011 H Blanking R (6~5 V Shift (3~0)
46 VSC 0A 0E* 00001110 Vertical S Correction (4~0)
47 VTS6VC3CDM 38 28* 00101000 V Test (7~6) V Compression (5~3)Count Down Mode (0)
48 FBS4GRY2CRS 10 10 00010000 VNS (7) V Blk (6~5) FBP Blk (4) Gray Mode (2) CRS (1~0)
49 RB 00 00 00000000 Red Bias (7~0)
4A GB 00 00 00000000 Green Bias (7~0)
4B BB 00 00 00000000 Blue Bias (7~0)
4C RD 40 40 01000000 Red Drive (6~0)
4D GD 08 08 00001000 Green Drive (3~0)
4E BD 40 40 01000000 Blue Drive (6~0)
4F SBI 40 30* 00110000 Sub Bias (6~0)
50 ↓↓↓↓Not Used
51 ↓↓↓↓Not Used
52 OSD 03 03 00000011 On Screen Display Contrast (1~0)
53 ABL5MSD4RTS3BAT 04 0C* 00001100 ABL Defeat (5) MID Stop (4) RGB Temp (3) ABL Thresh (2~0)
54 CRG 12 12 00010010 Coring Gain (7~6)
55 STR4FLS 41 21* 00100001 S Trap Test (6~4) Y/C Filter Mode (2~0)
56 YAP6PRE4OVR2WP 00 00 00000000 Y APF (6) Pre Shoot (5~4) Over Shoot (3~2) White Peak (1~0)
57 YGM6DCR4BSS2BSG 04 04 00000100 Y Gam (7~6) DC Res (5~4) B Strk Start (3~2) B Strk Gain (1~0)
58 CBT3 60 60 01100000 Cb Trap (7~3)
59 ↓↓↓↓Not Used
5A ↓↓↓↓Not Used
5B AF7CBP5 20 A0* 10100000 Auto Flesh (7) C Bypass (5)
5C CKO 07 03* 00000011 Color Killer (2~0)
5D RYA 08 08 00001000 R-Y/B-Y Angle (3~0)
5E CBO4CRO 98 98 10011000 Cb DC Offset (7~4) Cr DC Offset (3~0)
5F GYA3 00 00 00000000 G-Y Angle (3)
60 ↓↓↓↓Not Used
61 FMM5 00 00 00000000 FM Mute (5)
62 IAS7STS6RAD 60 60 01100000 IF AGC (7) S Trap SW (6) RF AGC (5~0)
63 VIF5VL 10 10 00010000 VIF System SW (5) Video Level (4~2)
64 VCO1 80 80 10000000 VCO Freq (7~1)
65 OMS6OML 20 20 00100000 Over Mod SW (6) Over Mod Level (5~2)
66 ↓↓↓↓Not Used
67 VMD6VMG3SSN 24 22* 00100010 VM delay (7~6) VM Gain (5~3) Sync Sep Sens(2~0)
68 ↓↓↓↓Not Used
69 EWD 2E 2A* 00101010 E/W DC (5~0)
6A EWA 12 16* 00010110 E/W Amp (5~0)
6B EWT 23 29* 00101001 E/W Tilt (5~0)
