— 5 —
Table 1. ON-SCREEN SERVICE MENU (Continued)
When IC802 (EEPROM) is replaced, check the bus data to confirm they are the same as below. The shaded menu should be
checked and be set up or readjusted according to the procedures described in the following pages. Initial Setup Data
marked with an * should be changed from Initial Reference Data. (See page 3 for Initial Bus Data Setup.)
NO. TITLE
INITIAL REFERENCE INITIAL SETUP
RANGE OF DATA FUNCTION
DATA DATA
46 VL 4 4 0~7 Video Level
47 EWD 39 39 0~63 EW DC
48 EWA 30 26* 0~63 EW Amp
49 EWT 34 33* 0~63 EW Tilt
50 EWP 7 9* 0~7 EW Corner Top
51 EWB 8 10* EW Corner Bottom
52 HSC 4 5* Horz Size Comp
53 SB 32 32 0~63 Sub Bright
54 SCO 7 7 0~31 Sub Color
55 STI 20 14* 0~31 Sub Tint
56 SSH 12 12 0~31 Sub Sharpness
57 OPT 0 16* 0~255 Option (See Note 1 page 6.)
58 OP2 0 66* 0~255 Option 2 (See Note 2 page 6.)
59 HR 24 24 0~63 OSD Horizontal Position
60 ATT 10 10 0~63 Input Level
61 WDB 32 32 0~63 Wideband
62 SPC 32 32 0~63 Spectral
63 SBO 5 5 0~255 Sub Bright Offset
64 PCO 40 40 0~63 PIP Color
65 PTI 40 40 0~63 PIP Tint
66 PUV 24 24 0~63 PIP Top Position
67 PDV 147 147 0~255 PIP Bottom Position
68 PLH 10 10 0~63 PIP Left Position
69 PRH 101 101 0~255 PIP Right Position
70 PCN 42 42 0~63 PIP Y Level
71 PBS 15 15 0~63 PIP BGP Phase
72 DRV
64 64 0~127 Red Drive Adjustment (See Note 3 page 6.)
64 64 0~127 Blue Drive Adjustment (See Note 3 page 6.)
– 0 0 0~255 Red Bias Adjustment (See Note 4 page 6.)
73 – 0 0 0~255 Green Bias Adjustment (See Note 4 page 6.)
– 0 0 0~255 Blue Bias Adjustment (See Note 4 page 6.)
To Next Page
