— 5 —
Table 1. ON-SCREEN SERVICE MENU
When IC802 (EEPROM) is replaced, check the bus data to confirm they are the same as below. The shaded menu should be
checked and be set up or readjusted according to the procedures described in the following pages. Initial Setup Data marked
with an * should be changed from Initial Reference Data. (See pages 3 and 4 for Initial Bus Data Setup.)
No. TITLE
INITIAL REFERENCE INITIAL SETUP INITIAL SETUP
FUNCTION
DATA HEX DATA HEX DATA BINARY
3C SCO 0F 25* 00011011 Sub Color
3D STI 15 0C* 00001110 Sub Tint
3E SB 20 20 00100000 Sub Bright
3F SSH 08 02* 00000101 Sub Sharpness
40 AFC6HFR A5 BF* 10111111 AFC(6) Horizontal Frequency
41 VTR7HP 0C 12* 00001111 Vertical Trans(7) Horizontal Phase
42 VS 40 2F* 00111110 Vertical Size
43 VSP7VPO 2A 20* 00101111 Vertical Sync Separator(7) Vertical Position
44 CDM5UVL 06 0F* 00001011 Vetical Count Down Mode(5) Vertical Linearity Top
45 VC5LVL 9E 4A* 01001101 Vertical Compression(5) Vertical Linearity Bottom
46 VSC 14 0C* 00010010 Vertical S Correction
47 RB 00 00 00000000 Red Bias
48 GB 00 00 00000000 Green Bias
49 BB 00 00 00000000 Blue Bias
4A RD 38 3A* 00111010 Red Drive
4B HT5HTD4GD 37 37 00110111 Half Tone(6~5) Half Tone Defeat(4) Green Drive
4C BD 38 3A* 00111010 Blue Drive
4D SBI 30 44* 00010111 Sub Bias
4E ↓↓↓↓Not Used
4F ↓↓↓↓Not Used
50 OSD 07 06* 00001010 On Screen Display Contrast
51 CRG6 80 80 10000000 Coring
52 ↓↓↓↓Not Used
53 ↓↓↓↓Not Used
54 FLS 84 83* 10000011 Y/C Filter Mode
55 GRY7CRS5GYA3CKO 03 03 00000011 Gray(7) Cross B/W(6~5) G-Y Angle(4) Color Killer
56 FBP6YAP4WP 42 42 01000001 FBP Blanking(6) Y APF(4) White Peak
57 YGM6DCR4BSS2BSG A5 A1* 01100001 Y Gamma(7~6) DC Reset(5~4) B Strk Start(3~2)B Strk Gain
58 AFC7CBP5 40 C0* 11000000 Auto Flesh(7) Color Band Pass Filter(5)
59 DIG6ABL5MSD4BAT 44 64* 01100100 OSD D/A(6) ABL Defeat(5) Mid Stop(4) ABL Threshold
5A RYA 0B 00* 00000000 R-Y/B-Y Angle
5B CBO4CRO 88 88 10001000 Cb DC Offset(7~4) Cr DC Offset
5C ↓↓↓↓Not Used
5D STS7RAD 20 20 00100000 S Trap Switch(7) RF AGC Delay
5E FMM7VIF4IAS 00 00 00000000 FM Mute(7) VIF System Switch(4) IF AGC
5F VL5BPF A0 80* 10000000 Video Level(7~5) S BPF Switch
60 EWD 28 2B* 00011000 E/W DC
61 EWA 17 22* 00010100 E/W Amp
62 EWT 1D 21* 00100001 E/W Tilt
63 EWB4EWP 88 B8* 10111001 E/W Corner Bottom(7~4) E/W Corner Top
64 EWC7HLV6HSC 03 02* 00000101 E/W Correction Sw(7) H Lock V Det(6) H Size Comp
65 BOW4ANG 78 87* 10011001 Bow Correction(7~4) Angle Correction
66 PRE6OVR4CTT C0 20* 00100000 Preshoot Adj(7~6) Overshoot Adj(5~4) Chroma Trap Test
67 HBL4HBR 38 2A* 00111010 H Blanking Left(7~4) H Blanking Right
68 SSP5VM 90 90 10010000 Sync Sep Sens(7~5) VM Gain
69 VBL4 00 00 00000000 V Size 0.75(7) V Blanking Select
6A YTH2YGA 00 0D* 00001101 Y TH(3~2) Y Gain
6B RWD6ROF4BWD2BOF 00 10* 00010000 R Width(7~6) R Offset(5~4) B Width(3~2) B Offset
80 ATT 07 07 00000111 Attenuation (MTS Input Level)
