Table 1. ON-SCREEN SERVICE MENU (Continued)
— 6 —
SERVICE ADJUSTMENTS (Cont.)
No. TITLE
INITIAL REFERENCE INITIAL SETUP INITIAL SETUP
FUNCTION
DATA HEX DATA HEX DATA BINARY
81 WDB 20 20 00100000 Wide Band
82 SPC 20 20 00100000 Spectral
83 OPT 70 3C* 00111100 Aspect Ratio(5) Comb Filter(4) Clock(3) Scan Velocity(2)
84 OP2 52 2E* 00101110 V Guide(7) Tone(6) AV(5) PIP(4) F/V(3) I-Ch(2) C En(1) C En Sel
85 PUV 18 18 00011000 PIP Up Vertical Position
86 PDV 93 93 10010011 PIP Down Vertical Position
87 PLH 0A 0A 00001010 PIP Left Horizontal Position
88 PRH 65 65 01100101 PIP Right Horizontal Position
89 PCN 2A 2A 00101010 PIP Contrast
8A PBS 0F 0F 00001111 PIP BG Start
8B PCO 28 28 00101000 PIP Color
8C PTI 28 28 00101000 PIP Tint
8D HR 16 1C* 00011001 H Display Position
8E SBO 05 00* 00000000 Sub Bright Offset
8F DCN 00 00 00000000 YUV Sub Contrast
90 DBR 00 00 00000000 YUV Sub Bright
91 DCL 00 00 00000000 YUV Sub Color
92 DTN 00 FC* 11111100 YUV Sub Tint
93 DSP 00 00 00000000 YUV Sub Sharpness
94 DCG 00 00 00000000 YUV Sub Coring
95 DVM 00 00 00000000 YUV Sub VM
96 BDC 02 00* 00000000 YUV Cb Offset
97 RDC 02 00* 00000000 YUV Cr Offset
98 DHC 00 00 00000000 YUV Sub H Phase
99 DHS 00 00 00000000 YUV Sub E/W DC
9A ECN F4 F0* 11101001 16:9 Sub Contrast
9B EBR 00 FB* 11111011 16:9 Sub Bright
9C ECL 00 00 00000000 16:9 Sub Color
9D ETN 00 00 00000000 16:9 Sub Tint
9E EVS F9 F5* 11110111 16:9 Sub V Size
9F EVP 00 00 00000000 16:9 Sub V Position
A0 EEA F5 EF* 11111000 16:9 Sub E/W Amp
A1 EET FB FF* 00000010 16:9 Sub E/W Tilt
A2 EEP 00 FC* 11111111 16:9 Sub E/W Corner Top
A3 EEB FC FD* 00000000 16:9 Sub E/W Corner Bottom
A4 EUV FC FD* 11111110 16:9 Sub V Linearity Top
A5 ELV 00 03* 00000011 16:9 Sub V Linearity Bottom
A6 EWV 02 02 00000010 16:9 V Blanking Select
A7 SSN 02 02 00000010 Sync Separator Sense
A8 CDR 00 00 00000000 TV Count Down Mode
A9 AFR 00 00 00000000 AFC Loop Gain
AA B16 04 04 00000100 16:9 ABL VTH Sw
AB VFL 03 04* 00000100 Filter Sys (AV)
AC VCB 01 01 00000001 C Bypass (AV)
AD BWD 02 02 00000010 EWD AT AV Blue Back
AF DRV
R40 R40 01000000 Red Drive Adjustment (See Note 1.)
R40 R40 01000000 Blue Drive Adjustment (See Note 1.)
– - - - Red Bias Adjustment (See Note 2.)
– - - - Green Bias Adjustment (See Note 2.)
– - - Blue Bias Adjustment (See Note 2.)
