Sanyo DWM-1000 Service Manual

- 45 -
VOLTAGE OF IC & TRANSISTOR
IC113
(V)
Pin No. 12345678910111213141516
Power OFF 0V 0V 0V 0V 4.9V 0V 4.9V 0V 4.6V 0V 3.2V 0V 3.2V 0V 3.3V 0V
Power ON 0V 0V 0V 0V 4.9V 0V 4.9V 0V 4.6V 0V 3.2V 0V 3.3V 0V 3.3V 0V
Pin No. 17 18 19 20
Power OFF 0V 0V 0V 4.9V
Power ON 0V 0V 0V 4.9V
IC116
(V)
Pin No. 12345678910111213141516
Power OFF 0V 2.5V 3.3V 0V 0V 0V 0V 0V 0V 0V 0V 3.3V 3.3V 3.3V 3.3V 3.3V
Power ON 0V 2.5V 3.3V 0V 0V 0V 0V 0V 0V 0V 0V 3.3V 3.3V 3.3V 0V 3.3V
Pin No. 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
Power OFF 3.3V 3.3V 0V 3.3V 3.3V 0V 3.3V 3.3V 3.3V 0V 0V 3.3V 0V 0V 0V 0V
Power ON 3.3V 3.3V 0V 3.3V 3.3V 0V 3.3V 3.3V 3.3V 0V 0V 3.3V 0V 0V 0V 0V
Pin No. 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
Power OFF 0V 0V 3.3V 3.3V 0V 3.3V 2.5V 0V 3.3V 0V 3.1V 0V 0.6V 3.1V 3.3V 2.7V
Power ON 0V 0V 3.3V 3.3V 3.3V 3.3V 2.5V 0V 3.3V 0V 3.1V 0V --- 3.2V 3.3V 2.7V
Pin No. 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64
Power OFF 0V 0V 0V 2.5V 2.5V 0V 1.6V 3.3V 0V 3.3V 3.3V 3.3V 0V 3.3V 3.3V 3.3V
Power ON 0V 0V 0V 2.5V 2.5V 0V 1.6V 3.2V 3.3V 3.3V 3.3V 0V 0V 3.3V 3.3V 3.3V
Pin No. 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
Power OFF 0V 0V 0.5V 0V 0V 3.3V 3.3V 0V 0V 3.3V 3.3V 3.3V 3.3V 3.3V 3.3V 3.3V
Power ON 0V 0V 3.3V 0V 0V 0V 3.3V 0V 0V 3.3V 3.1V 3.3V 3.3V 3.3V 3.2V 3.3V
Pin No. 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96
Power OFF 0V 2.5V 0V 3.3V 0V 0V 0V 3.3V 3.3V 3.3V 3.3V 3.3V 0V 3.3V 3.3V 0V
Power ON 0V 2.5V 3.3V 3.3V 0V 3.3V 0V 3.3V 3.3V 3.3V 3.3V 0V 3.3V 3.2V 3.3V 0V
Pin No. 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112
Power OFF 3.3V 0V 3.3V 0V 3.3V 0.4V 0V 0.6V 0.5V 0.5V 0.6V 0.5V 0V 3.3V 0.5V 0V
Power ON 3.3V 0V 3.3V 0V 2.7V --- --- --- --- --- --- --- 0V 3.3V --- 0V
Pin No. 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128
Power OFF 3.3V 3.3V 3.3V 3.3V 3.3V 0V 0V 3.3V 0V 2.5V 1.6V 0V --- --- --- ---
Power ON 3.3V 3.3V 3.3V 3.3V 3.3V 0V 0V 3.3V 0V 2.5V 1.6V 0V --- --- --- ---
Pin No. 129 130 131 132 133 134 135 136 137 138 139 140 141 142 143 144
Power OFF --- 0V 3.3V --- --- 0.6V 3.3V 3.3V 3.3V 3.3V 3.3V 0V 3.3V 0.1V 3.3V 0V
Power ON --- 0V 3.3V --- --- 1.1V 3.3V 3.3V 3.1V 3.1V 3.1V 0V 3.3V 0V 3.2V 0V
Pin No. 145 146 147 148 149 150 151 152 153 154 155 156 157 158 159 160
Power OFF 0V 0V 0V 0V 0V 0V 3.3V 0V 0V 0V 0V 0V 0V 0V 0V 3.3V
Power ON 0V 0V 0V 0V 0V 0V 3.3V 0V 0V 0V 0V 0V 0V 0V 0V 3.3V
IC117
(V)
Pin No. 12345678910111213141516
Power OFF 3.3V --- --- 0V --- --- 3.3V --- 0.3V 0V 0.3V 0.3V 3.3V 0V 2.1V 2.6V
Power ON 3.3V --- --- 0V --- --- 3.3V --- --- 0V --- --- 3.3V 0V 3.3V 3.2V
Pin No. 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
Power OFF 2.5V 11.9V 0V 0V 2.3V 2.4V 0.8V 1.7V 3.3V 0V 3.2V 1.7V 1.5V 3.1V 1.8V 0V
Power ON 3.3V 3.2V 0.2V 0.1V 3.1V 3.2V 3.1V 0V 3.3V 0V 0V 0.2V 3.3V 0V 0V 0V
Pin No. 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
Power OFF 0V 3.3V 1.6V 0V 0V 3.3V --- --- 0V --- --- 3.3V --- --- 0V ---
Power ON 0V 3.3V 1.6V 0V 0V 3.3V --- --- 0V --- --- 3.3V --- --- 0V ---
Pin No. 49 50
Power OFF --- 0V
Power ON --- 0V
IC118
(V)
Pin No. 12345678910111213141516
Power OFF 0V --- 0V 0V 0.1V 3.2V 0V --- 3.3V 0V 0V 0V 0V 0V 0V 0V
Power ON 0.1V --- 0.1V 0.1V 0.1V 3.1V 0.1V --- 3.3V 0.1V 0V 0.1V 0.1V 3.3V 0.1V 0V
Pin No. 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
Power OFF 0V --- 3.1V 3.2V 0.1V 0.1V 0V 0.1V 0V 0.1V 0V 0V --- --- --- ---
Power ON 0V 0V 0V 3.3V 0V 0.1V 0V 3.3V 3.3V 3.3V 0V 3.2V --- --- --- ---
Pin No. 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
Power OFF --- --- --- --- 3.3V 0V --- --- --- --- --- --- --- --- 0V 0V
Power ON --- --- --- --- 3.3V 0V --- --- --- --- --- --- --- --- 0V 0.1V
