PARTS LIST

REF.NO. PART NO. DESCRIPTION

D4104 407 218 9205 ZENER DI0DE KDZ15V(XE,UK)

or 407 187 8001 ZENER DIODE UDZ10B

or 407 206 5608 ZENER DIODE UDZS10B

or 407 179 1003 ZENER DIODE UDZ15B

or 407 218 7409 ZENER DIODE UDZS15B

D4105 407 218 9205 ZENER DI0DE KDZ15V(XE,UK)

or 407 187 8001 ZENER DIODE UDZ10B

or 407 206 5608 ZENER DIODE UDZS10B

or 407 179 1003 ZENER DIODE UDZ15B

or 407 218 7409 ZENER DIODE UDZS15B

D4106 407 218 9205 ZENER DI0DE KDZ15V(XE,UK)

or 407 187 8001 ZENER DIODE UDZ10B

or 407 206 5608 ZENER DIODE UDZS10B

or 407 179 1003 ZENER DIODE UDZ15B

or 407 218 7409 ZENER DIODE UDZS15B

D4107 407 218 9205 ZENER DI0DE KDZ15V(XE,UK)

or 407 187 8001 ZENER DIODE UDZ10B

or 407 206 5608 ZENER DIODE UDZS10B

or 407 179 1003 ZENER DIODE UDZ15B

or 407 218 7409 ZENER DIODE UDZS15B

D4108 407 218 9205 ZENER DI0DE KDZ15V(XE,UK)

or 407 187 8001 ZENER DIODE UDZ10B

or 407 206 5608 ZENER DIODE UDZS10B

or 407 179 1003 ZENER DIODE UDZ15B

or 407 218 7409 ZENER DIODE UDZS15B

D4109 407 218 9205 ZENER DI0DE KDZ15V(XE,UK)

or 407 187 8001 ZENER DIODE UDZ10B

or 407 206 5608 ZENER DIODE UDZS10B

or 407 179 1003 ZENER DIODE UDZ15B

or 407 218 7409 ZENER DIODE UDZS15B

D4110 407 218 9205 ZENER DI0DE KDZ15V(XE,UK)

or 407 187 8001 ZENER DIODE UDZ10B

or 407 206 5608 ZENER DIODE UDZS10B

or 407 179 1003 ZENER DIODE UDZ15B

or 407 218 7409 ZENER DIODE UDZS15B

D4111 407 218 9205 ZENER DI0DE KDZ15V

or 407 187 8001 ZENER DIODE UDZ10B

or 407 206 5608 ZENER DIODE UDZS10B

or 407 179 1003 ZENER DIODE UDZ15B

or 407 218 7409 ZENER DIODE UDZS15B

D4112 407 218 9205 ZENER DI0DE KDZ15V

or 407 187 8001 ZENER DIODE UDZ10B

or 407 206 5608 ZENER DIODE UDZS10B

or 407 179 1003 ZENER DIODE UDZ15B

or 407 218 7409 ZENER DIODE UDZS15B

D4113 407 012 4406 DIODE 1SS133(XE,UK)

D4114 407 012 4406 DIODE 1SS133(XE,UK)

D4954 407 012 4406 DIODE 1SS133

D4955 407 012 4406 DIODE 1SS133

D4956 407 012 4406 DIODE 1SS133

D4957 407 012 4406 DIODE 1SS133

D4958 407 099 9509 ZENER DIODE MTZJ30B

D4959 407 099 5204 ZENER DIODE MTZJ5.1B

D4960 407 099 4603 ZENER DIODE MTZJ3.9B

D4961 407 012 4406 DIODE 1SS133

D4962 407 099 6102 ZENER DIODE MTZJ10B

D4963 407 012 4406 DIODE 1SS133

D4964

407 097 8009 DIODE MPG06G(XE,UK)

D4965

407 097 8009 DIODE MPG06G(XE,UK)

D4966 407 012 4406 DIODE 1SS133

D4970

407 097 8009 DIODE MPG06G

D4971

407 097 8009 DIODE MPG06G

D4972

407 098 3300 DIODE RL153-BF-S2

D4973

407 098 3300 DIODE RL153-BF-S2

D4974 407 099 4603 ZENER DIODE MTZJ3.9B

D4975 407 099 6805 ZENER DIODE MTZJ13B

D4976 407 099 6805 ZENER DIODE MTZJ13B

HS410 614 270 2598 HEAT SINK

IC410 409 499 5907 IC MM1508XNRE,MM1508XNRE

IC495

409 463 6701 IC KIA7805API

409 145 2809 IC NJM7805FA

L4100 645 034 7887 INDUCTOR,1000 OHM(XE,UK)

or 645 020 1813 INDUCTOR,1000 OHM

L4101 645 034 7887 INDUCTOR,1000 OHM(XE,UK)

or 645 020 1813 INDUCTOR,1000 OHM

LUG41 645 023 8987 FIXER

PR410

645 042 2577 PROTECTOR,0.8A 125V(XE,UK)

645 014 2505 PROTECTOR,0.8A 125V

PR411

645 027 4169 PROTECTOR,0.125A 125V

PR495

645 042 2720 PROTECTOR,5A 125V

PR496

645 042 2720 PROTECTOR,5A 125V

PR497

645 042 2577 PROTECTOR,0.8A 125V

645 014 2505 PROTECTOR,0.8A 125V

PR498

645 027 4169 PROTECTOR,0.125A 125V

Q4100 405 151 4400 TR KTD1303

or 405 021 0204 TR 2SD1012-F-SPA

or 405 021 0600 TR 2SD1012-G-SPA

or 405 033 6706 TR 2SD1468S-R

or 405 033 6805 TR 2SD1468S-S

Q4101 405 151 4400 TR KTD1303

or 405 021 0204 TR 2SD1012-F-SPA

or 405 021 0600 TR 2SD1012-G-SPA

or 405 033 6706 TR 2SD1468S-R

or 405 033 6805 TR 2SD1468S-S

Q4102 405 146 2107 TR KTC3875-Y(XE,UK)

or 405 146 2206 TR KTC3875-GR

or 405 014 4509 TR 2SC2412K-R

or 405 011 1006 TR 2SC1623-L6

Q4120 405 146 1605 TR KRC102S(XE,UK)

or 405 000 2908 TR DTC114EK

Q4121 405 146 5306 TR KRA102S(XE,UK)

or 405 000 0409 TR DTA114EK

Q4950 405 141 3703 TR KTA1271-Y

or 405 008 2405 TR 2SB698-F

or 405 008 2504 TR 2SB698-G

Q4951 405 146 1704 TR KTA1504-Y

or 405 146 9700 TR KTA1504-GR

or 405 005 5508 TR 2SA812-M6

Q4952 405 146 1704 TR KTA1504-Y

or 405 146 9700 TR KTA1504-GR

or 405 005 5508 TR 2SA812-M6

Q4970 405 143 6504 TR KTA1267-GR

or 405 004 4601 TR 2SA608-F-SPA

or 405 004 5103 TR 2SA608-G-SPA

or 405 006 1806 TR 2SA933S-R

or 405 006 1905 TR 2SA933S-S

Q4971 405 143 6504 TR KTA1267-GR

or 405 004 4601 TR 2SA608-F-SPA

or 405 004 5103 TR 2SA608-G-SPA

or 405 006 1806 TR 2SA933S-R

or 405 006 1905 TR 2SA933S-S

Q4973 405 143 8706 TR KTC3199-GR

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

or 405 011 8500 TR 2SC1740S-R

or 405 011 8609 TR 2SC1740S-S

Q4974 405 143 8706 TR KTC3199-GR

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

or 405 011 8500 TR 2SC1740S-R

or 405 011 8609 TR 2SC1740S-S

Q4975 405 143 8706 TR KTC3199-GR

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

or 405 011 8500 TR 2SC1740S-R

or 405 011 8609 TR 2SC1740S-S

R4960

402 084 7201 FUSIBLE RES 18

R4970 401 105 1709 MT-GLAZE 150K JA 1/16W(XE,UK)

R4971 401 105 8104 MT-GLAZE 56K JA 1/16W(XE,UK)

R4974

402 081 0601 RESISTOR 1K J- 2W

R4975

402 081 8904 RESISTOR 1 J- 1/2W

S4100 645 040 6102 SWITCH,SLIDE 2P-2TX4

SH410 614 314 7176 SHIELD,SCART(XE,UK)
