30
Power/B to Main board Power/B to Panel Inverter/B(LG panel)
SSE55T
DC02P01670I
760 mm
SSE55T
DC02P00780I (for LG panel)
410 mm
SSE55T
DC02P00760I(for LG panel)
680 mm
Power/B P802 Main board CN2 Power/B P803 Panel BL Power/B P804 Panel BL
A2008H00-16P Color A2001H02-16P A2008H00-14P Color A2001H02-14P A2008H00-14P Color A2001H02-12P
1 GND Black 1 GND 1 24Vcc Black 1 24Vcc 1 24Vcc Black 1 24Vcc
2 GND Brown 2 GND 2 24Vcc Brown 2 24Vcc 2 24Vcc Brown 2 24Vcc
3 24Va Red 3 Audio power 3 24Vcc Red 3 24Vcc 3 24Vcc Red 3 24Vcc
4 24Va Orange 4 Audio power 4 24Vcc Orange 4 24Vcc 4 24Vcc Orange 4 24Vcc
5 GND Yellow 5 GND 5 24Vcc -- 5 24Vcc 5 24Vcc -- 5 24Vcc
6 GND Green 6GND 6GND Green 6 GND 6GND Green 6GND
7 GND Blue 7 GND 7 GND Blue 7 GND 7 GND Blue 7 GND
8 12Vcc Purple 8 12V panel 8 GND Purple 8 GND 8 GND Purple 8 GND
9 12Vcc Gray 9 12V panel 9 GND Gray 9 GND 9 GND Gray 9 GND
10 5Vcc White 10 5V standby 10 GND -- 10 GND 10 GND -- 10 GND
11 5Vcc Black 11 5V standby 11 NC -- 11 DET 11 NC -- 11 NC
12 5Vcc -- 16 BL_ERROR 12 BL_ON Brown 12 VBLON 12 BL_ON -- 12 NC
13 PW_ON Red 12 PW_EN 13 DIM Black 13 PDIM 13 DIM --
14 ACD Orange 13 PG 14 NC -- 14 NC 14 NC --
15 DIM Yellow 15 BL_DIM
16 BL_ON Green 14 BL_EN
