31
Power/B to Panel Inverter/B(AUO panel)
SSE55T
DC02P00710I (for AUO panel)
410 mm
SSE55T
DC02P00720I (for AUO panel)
680 mm
Power/B P803 Panel BL
ower/B P804 Panel BL
A2008H00-14P Color A2001H02-14P A2008H00-14P Color A2001H02-14P
1 24Vcc Black 1 24Vcc 1 24Vcc Black 1 24Vcc
2 24Vcc Brown 2 24Vcc 2 24Vcc Brown 2 24Vcc
3 24Vcc Red 3 24Vcc 3 24Vcc Red 3 24Vcc
4 24Vcc Orange 4 24Vcc 4 24Vcc Orange 4 24Vcc
5 24Vcc -- 5 24Vcc 5 24Vcc -- 5 24Vcc
6 GND Green 6 GND 6 GND Green 6 GND
7 GND Blue 7 GND 7 GND Blue 7 GND
8 GND Purple 8 GND 8 GND Purple 8 GND
9 GND Gray 9 GND 9 GND Gray 9 GND
10 GND -- 10 GND 10 GND -- 10 GND
11 NC -- 11 DET 11 NC -- 11 DET
12 BL_ON Brown 12 VBLON 12 BL_ON Brown 12 VBLON
13 DIM Black 14 PDIM 13 DIM Black 14 PDIM
14 NC -- 13 VDIM 14 NC -- 13 VDIM
To Next Page
