Sanyo MCD-Z100F User Manual

POWER SUPPLY
.—— L— ————— .
~ Battery power operation ~
L.—--———-—— ——J
Install batteries.
Observe + and - signs.
8 “D” size batteries
H
-%
Replace lid.
——— A——
[ IC—pow:r operation ]
—
—— _—
Take out the cord and connect it.
AC INPUT
50Hz
NOTES:
The FUNCTION switch is mounted on the sec-
ondary side. The unit is not disconnected from
mains, even switched off.
- When the mains lead is connected to the unit,
the installed batteries will be automatically dis-
connected
CAUTION:
WHEN INSTALLING THE BATTERIES
To prevent leakage from the batteries, which is corrosive and can cause personal injury and damage
to the unit, observe the following precautions:
1. The batteries must be installed correctly. Match the polarities (+ and – signs) on the batteries, to
the polarities shown on the back of the unit.
2. Do not mix new batteries with old or used batteries.
3. Only use batteries of the same type and brand.
4. If the unit will not be used for an extended period of time, remove the batteries and store them in
a cool place.
5. Carefully follow the battery manufacturer’s instructions for proper use and disposal.
6. DO NOT ALLOW YOUNG CHILDREN TO HANDLE BATTERIES.
NOTE:
When the batteries have become discharged, they must be disposed of in a safe manner which
complies with all applicable laws.
-2-

Sanyo MCD-Z100F Specifications

Power

ac_power_source	230-240 V, 50 Hz
dc_power_source	12 V (8 "D" size batteries)
output_power	3.0 W x 2 (DC max.)

Audio Specifications

frequency_response	80-12, 000 Hz (Normal tape)
s_n_ratio	70 dB
wow_flutter	undetectable

Radio Specifications

am_tuning_range	525-1710 kHz
fm_tuning_range	87.5-108 MHz
aerials	Built-in ferrite bar and telescopic rod aerials

CD Specifications

sampling_frequency	44.1 kHz
quantization	16 bits linear/ch
pick_up_wave_length	790 nm

Weight and Dimensions

dimensions	460x155x250 mm
weight	3.2 kg
