PARTS LIST
PRODUCT SAFETY NOTICE
EACH PRECAUTION IN THIS MANUAL SHOULD BE FOLLOWED DURING SERVICING. COMPONENTS IDENTIFIED WITH THE IEC
SYMBOL
!
!!
IN THE PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATED COMPONENTS IN WHICH SAFETY CAN BE OF
SPECIAL SIGNIFICANCE. WHEN REPLACING A COMPONENT IDENTIFIED BY
!
!!
, USE ONLY THE REPLACEMENT PARTS DESIGNATED,
OR PARTS WITH THE SAME RATINGS OF RESISTANCE, WATTAGE OR VOLTAGE THAT ARE DESIGNATED IN THE PARTS LIST
IN THIS MANUAL. LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS MUST BE MADE TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT BEFORE RETURNING THE PRODUCT TO THE CUSTOMER.
PACKING & ACCESSORIES
REF.NO. PART NO. DESCRIPTION
614 318 0791 CARTON CASE,INNER SLEEVE
(DC-X8CT/UK)
614 317 7999 CARTON CASE,INNER SLEEVE
(RD-088/XE)
614 317 8019 CARTON CASE, PRINT INNER
(RD-X8/UK-2)
614 319 0967 CARTON CASE, PRINT INNER
(RD-088/SP)
614 316 2766 CUSHION,FRONT
(DC-X8CT/UK)
614 319 4385 CUSHION,FRONT(RD-088/XE,
RD-X8/UK-2 & RD-088/SP)
614 316 2773 CUSHION,BACK
(DC-X8CT/UK)
614 319 4392 CUSHION,BACK
(RD-088/XE, RD-X8/UK-2
& RD-088/SP)
645 047 3074 POLY SHEET-0650X0400*NC,SET
(DC-X8CT/UK & RD-088/SP)
645 047 3081 POLY SHEET-0650X0400*NC,SET
(RD-088/XE)
CABINET & CHASSIS
REF.NO. PART NO. DESCRIPTION
1 614 317 7470 ASSY,CABINET,FRONT
(DC-X8CT/UK, RD-088/XE
& RD-X8/UK-2)
1 614 319 1094 ASSY,CABINET,FRONT(RD-088/SP)
2 614 316 2094 BUTTON,OPEN/CLOSE
(DC-X8CT/UK,RD-088/XE
& RD-X8/UK-2)
2 614 319 0691 BUTTON,OPEN/CLOSE(RD-088/SP)
3 614 316 2353 DEC,ESC,LIGHTING
(DC-X8CT/UK, RD-088/XE
& RD-X8/UK-2)
3 614 316 2360 DEC,ESC,LIGHTING(RD-088/SP)
4 614 316 2360 DEC,WINDOW,LIGHTING
(DC-X8CT/UK, RD-088/XE
& RD-X8/UK-2)
4 614 316 2353 DEC,WINDOW,LIGHTING(RD-088/SP)
5 614 316 2605 REFLECTOR,LED
6 614 302 0530 DEC,WINDOW LED,REC/PAUSE,
COMP/REC
7 614 316 2407 DEC,WINDOW,LED,PLAY(ARROW)
8 614 316 2124 BUTTON,DOLBY
(DC-X8CT/UK, RD-088/XE
& RD-X8/UK-2)
8 614 319 1100 BUTTON,DOLBY(RD-088/SP)
9 614 316 2131 BUTTON,PLAY,PLAY/REV
(DC-X8CT/UK, RD-088/XE
& RD-X8/UK-2)
ELECTRICAL PARTS
REF.NO. PART NO. DESCRIPTION
51 614 316 7440 ASSY,WIRE,TRAY MOTOR
52 614 316 7426 ASSY,WIRE,R/P&E.HEAD LEAD
53 614 316 7433 ASSY,WIRE,MECHA
FIXING PARTS
REF.NO. PART NO. DESCRIPTION
Y01 411 021 3503 SCR S-TPG BIN 3X10,
FRONT-BOTTOM-FIX
Y02 411 165 3803 SCR S-TPG BIN 2.3X10,
FRONT-PWB/EJECT
Y03 411 165 3803 SCR S-TPG BIN 2.3X10,
FRONT-REFLECTOR LED
Y04 411 165 3803 SCR S-TPG BIN 2.3X10,
FRONT-PWB/BUTTON
Y05 411 098 4205 SCR S-TPG BIN 3X8,CABINET
Y06 411 020 8905 SCR S-TPG BRZ+FLG 3X10,
BOTTOM-C/MECHA
Y07 411 021 3503 SCR S-TPG BIN 3X10,
BOTTOM-PWB/MAIN
Y08 411 021 3701 SCR S-TPG BIN 3X10,BOTTOM-REAR
Y09 411 021 3701 SCR S-TPG BIN 3X10,
REAR-ELECT PART
Y10 411 021 5705 SCR S-TPG BIN 3X6,BOTTOM-SHIELD
REF.NO. PART NO. DESCRIPTION
9 614 319 0721 BUTTON,PLAY,PLAY/REV(RD-088/SP)
10 614 316 2148 BUTTON,STOP
(DC-X8CT/UK, RD-088/XE
& RD-X8/UK-2)
10 614 319 0738 BUTTON,STOP(RD-088/SP)
11 614 317 7418 ASSY,CABINET,BENDING
12 614 316 2346 DEC,ESC,TRAY,CASSETTE TRAY
(DC-X8CT/UK, RD-088/XE
& RD-X8/UK-2)
12 614 319 0813 DEC,ESC,TRAY,CASSETTE TRAY
(RD-088/SP)
13 614 317 7494 ASSY,CABINET,BOTTOM
14 614 316 2551 PANEL,REAR
(DC-X8CT/UK & RD-X8/UK-2)
14 614 316 8843 PANEL,REAR
(RD-088/XE)
14 614 319 1131 PANEL,REAR(RD-088/SP)
15 614 316 7303 SHIELD,BOTTOM
16 614 130 0382 LUG,FRONT PWB
17 614 316 7297 SHIELD,TOP
CAUTION : Regular type resistors and capacitors are not listed. To know those values, refer to the schematic diagram.
Regular type resistors are less than 1/4 W Carbon type and Chip type resistors.
Regular type capacitors are less than 50 V and less than 1000 µF type of Ceramic type, Electrolytic type and Chip type.
