8
16 1440X900 - 60 - -
17 1680X1050 - 60 - -
18 1360X768 47.7 60 85.5 -
5.5 HDMI terminal
Input HDMI signal (VG849 signal generator), separately input the signals listed in table5 and table6
and check the display and sound (32KHz, 44.1KHz, 48KHz) at any situation (power on, channel
switch and format convert, etc.)
5.6 other functions check
a) Check the turn on/turn off timer, sleep timer, picture/sound mode, OSD, stereo and digital sound
port, etc.
b) Check the digital program, if Audio Only is normal.
c) Check MHEG function of the digital program for UK unit.
d) Check if “CI: Common Interface” is normal.
e) Check logical channel number (LCN) for Australia.
f) Check logical channel number (LCN) for France, UK and Italy.
g) Check OTA function for Australia special custom.
6. Presetting before ex-factory
6.1 Enter factory menu and select SSC ADJUST, set SSC MIU and SSC LVDS to ON.
6.2 Enter factory menu and select CUSTOM CHANNEL PRESET, press OK and about 10s the
operation will complete, press “list” and there are 5 channels in the list menu.
6.3 Enter user menu LOCK page, select “Restore Factory Default” to preset the ex-factory.
a) Clear the program information.
b) Clear VCHIP, parental control, etc.
c) Set the default data of user menu.
d) Set Menu Language to English.
e) Set Power on Mode to Off.
7. Software instruction
Table7 software instruction
No. Code No. Type Function written before
paste
Method
N810 5272532003 EN25B32-100HIP FLASH
Yes Written with device like ALL11,
write-protect, refer to note1.
N807 5272404002 AT24C04 HDMI KEY
Yes
NA03 5272402002 AT24C02 HDMI EDID
Yes
NA04 5272402002 AT24C02 HDMI EDID
Yes
NA08 5272402002 AT24C02
HDMI EDID
(Australia only)
Yes
N107 5272421002 AT24LC21A VGA EDID
Yes
Written with device like ALL11
Note1: write-protect setting: enter ALL-100 interface, select Config and press “config setting”, set
Protect to “All Protect”, select “config” when writing. The “write-protect” will be set again when
ALL-100 program restart.
