7
Table5 YUV signal format
No. Resolution
H-frequecny
(kHz)
V-frequecny
(kHz)
Point clock pulse
frequecny (MHz)
Note
1 720X480 15.734 60 13.5 480i(NTSC)
2 720X480 15.734 59.94 13.5 480i(NTSC)
3 720X576 15.625 50 13.5 576i(PAL)
4 720X480 31.469 60 27 480p(NTSC PROG)
5 720X480 31.469 59.94 27 480p(NTSC PROG)
6 720X576 31.25 50 27 576p(PAL PROG)
7 1280X720 45 59.94 74.18 720p(59p)
8 1280X720 45 60 74.25 720p(60p)
9 1280X720 37.5 50 74.25 720p(50p)
10 1920X1080 33.75 59.94 74.25 1080i(59i)
11 1920X1080 33.75 60 74.25 1080i(60i)
12 1920X1080 28.125 50 74.25 1080i(50i)
13 1920X1080 67.5 59.94 148.35 1080p(59p)
14 1920X1080 67.5 60 148.5 1080p(60p)
15 1920X1080 56.25 50 148.5 1080p(50p)
16 1920X1080 - 23.94/24 - -
17 1920X1080 - 25 - -
18 1920X1080 - 29.97/30 - -
5.4 VGA terminal
Input VGA signal (VG848 signal generator), separately input the signals listed in table6 and check
the display and sound. If the image is deflection of the Horizontal and vertical, select
Picture->Screen->Auto Adjusting to perform auto-correct.
Table6 VGA signal format
No. Resolution
H-frequecny
(kHz)
V-frequecny (kHz)
Point clock pulse
frequecny (MHz)
Note
1 640X480 31.469 59.94 25.175 IBM
2 720X400 31.469 70.086 28.322 IBM
3 640X480 37.861 72.809 31.5 VESA
4 640X480 37.5 75 31.5 VESA
5 800X600 35.156 56.25 36 VESA
6 800X600 37.879 60.317 40 VESA
7 800X600 48.077 72.188 50 VESA
8 800X600 46.875 75 49.5 VESA
9 1024X768 48.363 60.004 65 VESA
10 1024X768 56.476 70.069 75 VESA
11 1024X768 60.023 75.029 78.75 VESA
12 1152X864 67.5 75 108 VESA
13 1280X960 60 60 108 VESA
14 1280X1024 63.98 60.02 108 VESA
15 1280X1024 80 75 135 SXGA
