Identification of Controls
Main Unit (front view/side view)
Functions of CH , VOL , MENU, SOURCE and POWER are also provided to the remote control. This operation
manual provides a description based on operating functions with the remote control.
+/- +/-
Note
1. Indicator/Remote Sensor
2. CH+/-
Press these two buttons to directly change the TV channel;
In OSD menu, press these buttons to choose the OSD items.
3. VOL+/-
Press the VOL+ or VOL- button to directly increase or decrease the sound volume level;
In OSD menu, press these buttons to adjust the value or setting of each item.
4. MENU
Press this button to access Menu main page.
To access input source select menu.
POWER
5. SOURCE
6.
Press this button to turn the unit ON from STANDBY mode. Press it again to turn the set back to STANDBY.
1
6
2
3
4
5
Power Switch
