RCS-KR1EG
RCS-KR1EG
A
B
E
F
D
C
A. (Start/Stop)button
Pushing this button starts, and pushing again
stops the unit.
B. (Temperature setting) buttons
Changing the temperature setting.
C. (Mode Select) button
Pushing this button to select an operation
mode. (AUTO /HEAT /DRY /COOL
/
FAN ).
D. (Fan speed) button
Changing the fan speed.
E. (Swing/Air direction) button*1
Use this button to set the auto swing or air direction
to a specific angle.
*1 Do not move the flap (vertical airflow adjustment board)
with your hand.
The flap is automatically directed down when the
unit is stopped.
The flap is directed up during the HEAT standby.
The flap starts swinging after the HEAT standby is
cancelled, although the AUTO flap indication on the
remote control unit is displayed during the HEAT
standby.
F. (Outing function) button
( Outing Function)
Operation Section
2. Names and Operations
