9-2-3. Only outdoor unit does not run.
(1) Check setting temperature.
No
Is room temperature too low ?
No
Check to see if inter-unit wiring is
correctly connected between indoor
and outdoor unit.
COOL
1.
Try to lower setting temperature by
temperature setting button ( button).
2.
Does outdoor unit run ?
58
140
142
Table of Contents
Table of Contents
5
1 Operating Range
7
2 Specifications
8
Unit Specifications
8
Major Component Specifications
11
Other Component Specifications
17
3 Dimensional Data
18
4 Refrigerant Flow Diagram
21
5 Performance Data
23
Performance Charts
23
Air Throw Distance Charts
26
Cooling Capacity
29
Heating Capacity
32
6 Electrical Data
33
Electrical Characteristics
33
Electric Wiring Diagrams
36
7 Installation Instructions
40
Installation Site Selection
40
Recommended Wire Length and Diameter
42
Remote Control Unit Installation Position
43
How to Test Run the Air Conditioner
44
Removing and Installing the Grille
45
8 Functions
46
Room Temperature Control
46
Dry Operation (Dehumidification)
48
Automatic Switching between Cooling and Heating
49
Freeze Prevention (Cooling and Dry)
50
Automatic Fan Speed (Cooling and Dry)
51
Cold Draft Prevention (Heating)
52
Overload Prevention (Heating)
53
Automatic Fan Speed (Cooling, Dry and Heating)
54
Defrosting Operation (Heating)
55
9 Troubleshooting
56
Check before and after Troubleshooting
56
Air Conditioner Does Not Operate
57
Some Part of Air Conditioner Does Not Operate
61
Air Conditioner Operates, but Abnormalities Are Observed
63
10 Checking Electrical Components
64
Measurement of Insulation Resistance
64
Checking Continuity of Fuse on PCB Ass'y
65
Checking Motor Capacitor
65
11 Maintenance
66
Address Setting of the Remote Control Unit
66
Appendix Instruction Manual
67
Features
68
Alert Symbols
69
Electrical Requirements
69
Installation Location
69
Product Information
69
Safety Instructions
69
Names of Parts
70
Using the Remote Control Unit
74
Operation with the Remote Control Unit
75
Automatic Operation
75
Manual Operation
75
Adjusting the Fan Speed
76
Fan Only
76
ECONOMY Mode
76
Special Remarks
77
Using the 12-Hour on and off Timer
77
Using the 1-Hour off Timer
78
Adjusting the Airflow Direction
79
Tips for Energy Saving
79
Care and Cleaning
80
Operation Without the Remote Control Unit
80
Troubleshooting
82
Table of Contents
86
Default Chapter
88
Operating Range
88
2 Specifications
89
Unit Specifications
89
Other Component Specifications
98
3 Dimensional Data
99
4 Refrigerant Flow Diagram
102
5 Performance Data
104
Performance Charts
104
Air Throw Distance Charts
107
Cooling Capacity
110
6 Electrical Data
114
Electrical Characteristics
114
Electric Wiring Diagrams
117
7 Installation Instructions
121
Installation Site Selection
121
Removing and Installing the Grille
126
8 Functions
127
Room Temperature Control
127
Dry Operation (Dehumidification)
129
Automatic Switching between Cooling and Heating
130
Freeze Prevention (Cooling and Dry)
131
Automatic Fan Speed (Cooling and Dry)
132
Cold Draft Prevention (Heating)
133
Overload Prevention (Heating)
134
Automatic Fan Speed (Cooling, Dry and Heating)
135
Air Conditioner Does Not Operate
138
Some Part of Air Conditioner Does Not Operate
142
Air Conditioner Operates, but Abnormalities Are Observed
144
10 Checking Electrical Components
145
Measurement of Insulation Resistance
145
11 Maintenance
147
Address Setting of the Remote Control Unit
147
Appendix Instruction Manual
148
