Outdoor Unit SAP-C127GHAX
14
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Controller PCB
Compressor
Type Single Rotary
Compressor model / Nominal output C-R115H5A / 1,110W
Compressor oil ... Amount CC SAY-56T … 520
Coil resistance (Ambient temp. 25
C) Ohm C - R : 1.962
C - S : 5.38
Safety devices Type External (OLR)
Overload relay MRA98619-9200
Operating temp. Open
C 150 +/- 5
Close
C 69 +/- 11
Operating amp.(Ambient temp. 25
C) Trip in 6 to 16 sec. at 22.5A
Run capacitor
Micro F
25.0
VAC 400
Crankcase Heater -
Fan
Type Propeller
Q'ty … Dia. mm 1 … D380
Fan Motor
Type AC Motor
Fan motor model ... Q'ty UE4-Z51D5P R … 1
No. of poles 4
Rough Measure RPM (Cool/Heat) 1,070 / 1,020
Nominal output W 47.6
Coil resistance (Ambient temp. 20
C)
Ohm
(GRY)BRN - WHT : 152.1
RED - WHT : 138.7
Safety devices Type Thermal protector
Operating temp. Open
C
135
±
5
Close
C
86
±
15
Run capacitor
Micro F
2.5
VAC 450
Heat Exchanger Coil
Coil Aluminum Plate Fin / Copper Tube
Rows 1
Fin pitch mm 1.2
Face area
m
2
0.373
External Finish
Acrylic baked-on enamel finish
To Next Page
