2-3. Other Component Specifications
8
Thermostat (Fan Speed Control 23S) MQT5S
Switching temp. °C
high ➞ LOW 28.5°C ± 1.5
low ➞ HIGH 31.5°C ± 2
Contact rating AC 220V, 3A
Power Relay (PR) G7L-2A-TUB
Coil rating AC 200–240V, 50/60Hz
Coil resistance Ω (at 23°C) 21 ± 15%
Contact rating AC 220V, 25A
Outdoor Unit SAP–C181A
SAP–C241A
Thermistor (Room sensor) DTN-TKS142B
Resistance kΩ 25°C 5.0 ± 3%
Thermistor (Coil sensor) DTN-TKS131B
Resistance kΩ 0°C 15.0 ± 2%
Transformer (TR) ATR-J105
Rating Primary AC 230V, 50/60Hz
Secondary 19V, 0.526A
Capacity 10VA
Coil resistance Ω (at 21°C) Primary (WHT – WHT): 205 ± 10%
Secondary (BRN – BRN): 2.0 ± 10%
Thermal cut-off temp. 150°C
Indoor Unit SAP–K181A
SAP–K241A
