Vertical air flow distance (m)Vertical air flow distance (m)Vertical air flow distance (m)Vertical air flow distance (m)
Horizontal air flow distance (m)
Heating : Distribution of wind velocity
Heating : Distribution of temperature
0
1
2
3
0
1
2
3
Horizontal air flow distance (m)
0
1
2
3
0
1
2
3
(Strong wind : Discharge angle approx.65 ) (Room temperature approx.20 )
(Strong wind : Discharge angle approx.65 ) (Room temperature approx.20 )
1.5m/s
1.0m/s
0.5m/s
0.3m/s
33
27
24
30
Horizontal air flow distance(m)
Cooling : Distribution of wind velocity
Cooling : Distribution of temperature
0
1
2
3
0
1
2
3
Horizontal air flow distance (m)
0
1
2
3
0
1
2
3
(Strong wind : Discharge angle approx.30 ) (Room temperature approx.27 )
1.5m/s
1.0m/s
0.5m/s
0.3m/s
20
24
26
22
(Strong wind : Discharge angle approx.30 ) (Room temperature approx.27 )
SPW-XDR254GXH56(A/B), X255XH
4-79
1
2
3
4
5
6
7
8
3-WAY ECO-i SYSTEM Unit Specifi cations
2. 4-Way Air Discharge Semi-concealed Type (X, XM Types)
TD831143-00W-3WAY.indb79TD831143-00W-3WAY.indb79 2008/12/0117:23:182008/12/0117:23:18
