1. Specifications
1
MODEL No. Indoor Unit SPW-U363GH56
Outdoor Unit SPW-C363GH8
POWER SOURCE 380 - 400 - 415 V / 3N / 50 Hz
PERFORMANCE Cooling Heating
Capacity kW 10.6 11.4
BTU / h 36,000 39,000
Air circulation (Hi/Me/Lo) m3 / h 1,920/1,440/1,200
Moisture removal(High) Liters/h 3.9 -
External static pressure(High) mmAq(Pa) 7(69) : at shipment, 12(118) : using the booster cable
ELECTRICAL RATINGS
Voltage rating V 380 400 415 380 400 415
Available voltage range V 342 - 456 342 - 456
Running amperes* A 5.5 5.3 5.2 5.6 5.4 5.3
Max. running amperes** A 6.5 6.3 6.2 6.3 6.2 6.2
Power input kW 3.17 3.2 3.24 3.27 3.31 3.37
Power factor % 87.6 87.1 86.7 88.7 88.5 88.5
C.O.P W / W 3.34 3.31 3.27 3.49 3.44 3.38
Max. starting amperes A 31 33 35 31 33 35
FEATURES
Controls / Thermostat control Microprocessor / I.C. thermostat
Timer ON / OFF 72-hours
Fan speeds Indoor/Outdoor 3 and Automatic control/ 2 (Auto)
Airflow direction (Indoor) -
Air filter Field supply
Remote controller (Option) Wired:RCS-SH80TG
Refrigerant control Electronic Refrigerant Control Valve
Drain pump (drain connection) Max. head 25cm above drain connection (25A,OD32mm)
Compressor Rotary
Operation sound Indoor - Hi/Me/Lo dB - A 42 / 36 / 30, (46 / 42 / 38 : using the booster cable)
Outdoor - Hi dB - A 53
REFRIGERANT TUBING
Limit of tubing length m (ft.) 50 (164)
Limit of tubing length at shipment m (ft.) 30 (98)
Limit of elevation difference m (ft.) Outdoor unit is higher than indoor unit: 50 (164)
between the two units Outdoor unit is lower than indoor unit: 30 (98)
Refrigerant tube Narrow tube mm (in) 9.52 ( 3 / 8 )
outer diameter Wide tube mm (in) 19.05 ( 3 / 4 )
Refrigerant amount at shipment kg R22 - 3.5
DIMENSIONS & WEIGHT Indoor unit Outdoor unit
Unit dimensions Height mm (in) 310 (12-7/32) 1,235 (48-20/32)
Width mm (in) 1,480 (58-9/32) 940 (37)
Depth mm (in) 665 (26-6/32) 340 (13-12/32)
Package dimensions Height mm (in) 380 (14-31/32) 1,326 (52-7/32)
Width mm (in) 1,679 (66-3/32) 1,016 (40)
Depth mm (in) 866 (34-3/32) 416 (16-12/32)
Net weight kg (lb) 64 (141) 94 (207)
Shipping weight kg (lb) 71 (157) 101 (223)
Shipping volume m
3
(Cu. ft.) 0.553 (19.5) 0.56 (19.8)
DATA SUBJECT TO CHANGE WITHOUT NOTICE
Cooling :
Rating conditions(*) : Indoor air temperature 27
°
C DB / 19
°
C WB, Outdoor air temperature 35
°
C DB
Full load conditions
(
**
)
Indoor air temperature 35
°
C DB / 25
°
C WB, Outdoor air temperature 45
°
C DB
Heating :
Rating conditions(*) : Indoor air temperature 20
°
C DB, Outdoor air temperature 7
°
C DB / 6
°
C DB
Full load conditions
(
**
)
Indoor air temperature 24
°
C DB, Outdoor air temperature 24
°
C DB / 15.5
°
C WB
1-1 Unit Specifications

Sanyo SPW-C253GH5 Specifications
