Required operation privilege: admin, operator1, operator2
This function is available for JPEG streaming images only.
You can move the controller to the desired position by dragging with the mouse.
Click CLOSE to close the controller.
You can set clipping rectangles independently for each stream. To change the stream, select [LIVE
STREAM] on the CLIENT SETTINGS screen.
You can set up to four clipping rectangles anywhere in the image display area of the controller.
Setting a clipping rectangle:
Click anywhere on the image display area of the controller. This sets a VGA-size clipping rectangle at the
point you clicked.
Clipping rectangles may be set in an overlapping manner.
Selecting a clipping rectangle:
Click a clipping rectangle. The selected rectangle turns orange and the clipped area of the subject appears
on the live screen.
Deleting a clipping rectangle:
