30
Note:
1. Materials of Capacitors and Resistors are abbreviated as follows ;
Resistors Capacitors
MT-FILM Metallized Film Resistor MT-POLYEST Metallized Polyester Capacitor
MT-GLAZE Metallized Glaze Resistor MT-COMPO Metallized Composite Capacitor
OXIDE-MT Oxide Metallized Film Resistor TA-SOLID Tantalum Solid Capacitor
AL-SOLID Aluminum Solid Capacitor
NP-ELECT Non-Polarized Electrolytic Capacitor
OS-SOLID Aluminum Solid Capacitors with Organic
Semiconductive Electrolytic Capacitor
DL-ELECT Double Layered Electrolytic Capacitor
POS-SOLID Polymerized Organic Semiconductor Capacitor
2. Tolerance of Capacitor (10pF over) and Resistor are noted with follow symboles.
F ............1% G ............2% J ............5% K ............10%
M ..........20% N ..........30% Z ..........+80% ~ -20%
3. Capacitors
U : µF P : pF
4. Inductors
UH : µH MH : mH
5. N.S.P. : Not available as service parts.
ELECTRICAL PARTS
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
COMPL PWB,CP-1 F/W
636 113 7812
(SEMICONDUCTORS)
Q1301 405 218 3902 TR UP0431300
OR 305 167 0406 TR EMD12
Q1304 305 168 3703 TR DTC144EM
OR 305 216 1200 TR RN1104MFV
OR 305 172 4703 TR UNR32A3
Q1403 405 218 3902 TR UP0431300
OR 305 167 0406 TR EMD12
Q3001 305 210 5709 TR UP0KG8D
OR 305 217 3906 TR HN2E07JE
OR 305 200 9007 TR EML17
Q5006 405 219 2706 TR MCH5835-E
Q5008 305 210 5402 TR US5U29
Q5010 305 208 9702 TR SSM3J16TE
Q5301 305 215 6909 TR PMV40UN
Q9002 405 218 4107 TR UP0421500
OR 305 215 9504 TR EMH4
Q9005 305 173 4405 TR DTC114TM
OR 305 173 7406 TR UNR32A5
(INTEGRATED CIRCUITS)
IC101409 689 9500IC EV2LA B.G.A. (N.S.P.)
IC121410 641 7601IC K5W1213LCM-AK75 B.G.A. (N.S.P.)
IC181 409 684 9208 IC WM8941GEFL-V
IC182 309 650 3509 IC TK70630HC-G
IC301410 655 7604IC LC87F2924BUFL64TBM-E B.G.A. (N.S.P.)
IC302 309 582 6203 IC BD4289FVM
IC303 409 684 6801 IC XC61GN2502H-
IC501409 690 9209IC BD9631GU B.G.A. (N.S.P.)
IC502 409 689 0309 IC R1114D351D
IC901409 684 3206IC LR366877 B.G.A. (N.S.P.)
IC904 409 677 2803 IC NJM2877F3-03
IC905 409 690 2507 IC ADDI7000BCP
IC910 409 691 0601 IC XC6221S09XG
IC951 409 684 0707 IC LV8056LP
(DIODES)
D1701 307 244 0606 DIODE HSC226-E
D1702 307 244 0606 DIODE HSC226-E
D1703 307 244 0606 DIODE HSC226-E
D5301 307 250 0706 DIODE DRB060M-30
D9001 307 235 1001 DIODE MA2J72700L
D9003 307 208 0307 DIODE MA2S111
D9004 307 208 0307 DIODE MA2S111
(CRYSTAL DEVICES)
X1102 645 094 0170 OSC,CRYSTAL 48.00000MHZ
X3002 645 090 3298 OSC,CRYSTAL 32.768KHZ
(VARISTORS)
VA102 308 050 1207 VARISTOR AVR-M1608C120MT
VA131 308 050 0507 VARISTOR AVR-M1005C080MT
VA303 408 049 9907 VARISTOR AVR-M1005C080MT
VA304 408 049 9907 VARISTOR AVR-M1005C080MT
(INDUCTORS)
L1001 645 094 0521 IMPEDANCE,33 OHM P
L1301 645 095 6522 FILTER,EMI 90 OHM
L1304 945 053 5414 IMPEDANCE,1000 OHM P
L1306 945 020 1869 INDUCTOR,750 OHM
L5003 645 077 6465 INDUCTOR,10U M
L5004 645 084 3976 INDUCTOR,4.7U M
L5006 645 077 6465 INDUCTOR,10U M
L5007 645 095 9639 INDUCTOR,22U M
L5008 645 084 3976 INDUCTOR,4.7U M
L5301 645 096 0130 INDUCTOR,1.0U N
L9001 945 066 4725 IMPEDANCE,600 OHM P
L9002 945 066 4725 IMPEDANCE,600 OHM P
(CAPACITORS)
CB181 403 454 5100 CERAMIC 1U K 10V
CB301 303 392 5500 CERAMIC 1U K 6.3V
CB302 303 392 5500 CERAMIC 1U K 6.3V
CB903 303 391 4306 CERAMIC 0.1U K 16V
CB904 303 391 4306 CERAMIC 0.1U K 16V
CB906 403 454 5100 CERAMIC 1U K 10V
C1003 303 338 0309 CERAMIC 0.1U K 10V
C1007 303 338 0309 CERAMIC 0.1U K 10V
C1008 303 338 0309 CERAMIC 0.1U K 10V
C1009 303 376 8404 CERAMIC 4.7U K 6.3V
C1010 303 338 0309 CERAMIC 0.1U K 10V
C1011 303 338 0309 CERAMIC 0.1U K 10V
C1012 303 338 0309 CERAMIC 0.1U K 10V
C1013 303 384 6409 CERAMIC 4.7U K 6.3V
C1014 303 338 0309 CERAMIC 0.1U K 10V
C1017 303 384 6409 CERAMIC 4.7U K 6.3V
C1018 303 338 0309 CERAMIC 0.1U K 10V
C1028 303 338 0309 CERAMIC 0.1U K 10V
C1032 303 338 0309 CERAMIC 0.1U K 10V
C1033 303 276 1307 CERAMIC 1000P K 50V
C1121 303 311 7806 CERAMIC 8P D 50V
C1122 303 314 6400 CERAMIC 7P D 50V
C1202 303 338 0309 CERAMIC 0.1U K 10V
C1204 303 338 0309 CERAMIC 0.1U K 10V
C1205 303 338 0309 CERAMIC 0.1U K 10V
C1206 303 338 0309 CERAMIC 0.1U K 10V
C1207 303 384 6409 CERAMIC 4.7U K 6.3V
C1209 303 338 0309 CERAMIC 0.1U K 10V
C1211 303 384 6409 CERAMIC 4.7U K 6.3V
C1301 303 276 1703 CERAMIC 1P C 50V
C1303 303 433 1102 CERAMIC 1U K 10V
C1304 303 276 1703 CERAMIC 1P C 50V
C1306 303 433 1102 CERAMIC 1U K 10V
C1307 303 338 0309 CERAMIC 0.1U K 10V
C1308 303 338 0309 CERAMIC 0.1U K 10V
