SANYU SY2000 Series User Manual

- 3 -
1 General technical specifications and
product models
General technical specifications
Item
Description
Input
Rated voltage
frequency
380V or 220V：50HZ/60HZ
Allowable voltage
working range
Fluctuation range: ≤±20%; voltage unbalance rate: <3%; frequency: ±5%
Output
Rated voltage
0~380V or 0 ~220V
Frequency
0~999.9HZ
Overload capacity
100% rated current for 1 minute
Main
control
performan
ce
Control model
V/F control, advanced VF control, separate VF control, VF square curve
control, without PG current vector control
Modulation
Space voltage vector PWM modulation
Speed range
1: 100 (without PG vector control)
Starting torque
150% rated torque at 3.0 Hz (Advanced VF control)
Speed stabilization
accuracy
≤±0.2% rated synchronous speed
Speed fluctuation
≤±0.5% rated synchronous speed
Torque response
≤50ms without PG vector control
Torque control
Support torque control without PG vector control mode
Torque control accuracy:±5%
Frequency accuracy
Digital setting: maximum frequency×±0.01%;
Analog setting: maximum frequency×±0.2%
Frequency resolution
Digital setting: 0.01Hz;
Analog setting: maximum frequency×0.05%
Torque boost
Automatic torque boost, manual torque boost 0.1%~30.0%
V/F curve
6 control modes: 1 user setting V/F curve mode, 4 torque reduction
characteristic curve modes (2.0 power, 1.7 power, 1.5 power, 1.3 power)
and linear curve, square curve, multi-point VF curve
Acceleration and
deceleration curve
Linear acceleration and deceleration. Time unit (minutes/second) optional,
up to 999.9 seconds
DC braking
Starting frequency of DC braking at stop: 0.00-50.00HZ
Braking time: 0.0-30.0S; braking current: 0.0%-50.0% rated current
Automatic Voltage
Adjustment (AVR)
When the grid voltage changes, it can automatically keep the output
voltage constant
