Գ
LED Indicator
When turn on the SmartRig+, the
green indicator is on.
When choose +48V phantom power,
the red and green indicators are both
on.
When it is low battery, the red and
green indicators will be dim.
Դ
ON/OFF/+48V Switch
Select the ON/OFF switch to turn on/
off the SmartRig+.
Select +48V phantom power for
microphones that require phantom
power to operate.
Please notice that only the XLR inputs offer +48V phantom
power, the 1/8" (3.5mm) mic inputs do not offer +48V
phantom power.
Ե
Headphone Jack
Monitor the audio from inputs.
Զ
Output
1/8" (3.5 mm) output cable to smartphone/camera.
Է
Battery Compartment
Operates on one 9V alkaline or lithium battery (not
included).
1/4" Female Screw
