62
Output Format With 16 Characters
Display segments that are not activated are output as spaces.
Characters without a decimal point are output without a decimal point.
The following characters can be output, depending on the characters displayed
on the scale:
Normal Operation
Position 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
+*DDDDDDDD*UUUCRLF
or – ........ ***
or * ********
or 0 0 0 0 0 0
*: Space CR: Carriage return
D: Digit or letter LF: Line feed
U: Unit symbol
Special Codes
Position 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
******– –******CRLF
or H *
or L *
or C *
*: Space H: Overload
– –: Weight L: Underload
C: Calibration/adjustment
Error Codes
Position 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
*****E*###****CRLF
*: Space
# # #: Error code number
